RECIRCULATING FILTERS INSTALLATION
Installing Recirculating Filters (For Ductless Model Only)
Skip this page if you are installing a Ducted Range Hood.
Charcoal Filters are only included with Ductless Models
B
efore installing m
ake sure the unit is powered off and unplugged.
Additional Aluminum or Baffle Filters can be purchased from
www.cosmoappliances.com
1. Remove the Baffle Filters from the Range Hood
2. Locate Fig. 1 , unscrew the 6 screws along the Motor Ring (metal circle).
Set motor ring to the side.
3. Take your Filter Ring and align the holes on the motor ring to the holes of the filter ring.
4. Screw the Filter Ring into motor ring.
5. Take the
Carbon Filter and lock into the Filter Ring by aligning the two tabs and twisting.
6. Repeat Steps 1-5 on the other side.
7. Reattach the Baffle Filters.
The carbon filter must be replaced every 4-6 months depending on use.
Figure 1
Motor Ring
Filter Ring
Carbon Filter
Motor Housing
Note: This is a top venting unit and a hole must be cut into the cabinet for proper installation.
