Request Frame:
length
Description
Slave Address
1 Byte
0XA0 (AD Default Address)
Function Code
1 Byte
0x05
Starting Address MSB
1 Byte
0x00
Starting Address LSB
1 Byte
0x01
Register Value MSB
1 Byte
0x00
Register Value LSB
1 Byte
0x01
CRC LSB
1 Byte
CRC MSB
1 Byte
Response Frame:
length
Description
Slave Address
1 Byte
0XA0 (AD Default Address)
Function Code
1 Byte
0x05
Starting Address MSB
1 Byte
0X00
Starting Address LSB
1 Byte
0x01
Register Value MSB
1 Byte
0X00
Register Value LSB
1 Byte
0x01
CRC LSB
1 Byte
CRC MSB
1 Byte
FUNC
CODE
Starting
Address
Desc
Write
number
of byte
CMD AND RESPONSE
Value
5
0X0001
force to remote control &
setting power ON/Off
(POWER x)
2
Power on
A0 05 00 01 00 01 44
BB
A0 05 00 01 00 01 44
1: power on
0: power off
