Cotek AD-1500 - Modbus Function Code Write Coils Registers (0 X05)

To Next Page

To Previous Page

etc.

0X0073

Read Slave

S/N5~7(Master Only)

0X0074

Read All Output

Voltage(Vcap, Master

command only)

A0 04 00 74 00 08 A8 A7

A0 04 10 00 AF 00 96 00 00

00 00 00 00 00 00 00 00 00

00 ED 22

00 AF ->175

Master

Voltage

1.75v

00 96->150

Slave1

Voltage

1.5V

etc.

1-12. Modbus Function Code Write Coils Registers

(0x05)

This function code is used to write a single output to either ON or OFF in a remote

device. The requested ON/OFF state is specified by a constant in the request data

field. A value of FF 00 hex requests the output to be ON. A value of 00 00 requests

it to be OFF. All other values are illegal and will not affect the output.
