3. COTEK STANDARD PROTOCOL
3-1. Overview
Compatible with versions after 09-0000-1743 (INFO3?)
3-2. Wiring / connection of communication system
3-3. COTEK Standard Physical Communication
Physical Interface
Comments
RS485 Half-duplex
(Standard with different Setting)
Default baud rate: 19200 baud, none parity, 1 stop bit
UART (TTL level, Optional)
Default baud rate: 19200 baud, none parity, 1 stop bit
RS232 (Optional)
Default baud rate: 19200 baud, none parity, 1 stop bit
