COTES C35 OPERATING AND SERVICE HANDBOOK page 53/71
Replacing PLC
The following is standard procedure for replacing the PLC unit.
- Remove the top cover
- Disconnect cables for the PLC
- Remove the screws for the PLC bracket
- Replace the PLC
Replacing electrical board
The following is standard procedure for replacing an electrical board
• Open the top cover
• Disconnect all cables and sensors connected to the electrical board
• Remove the screws fastening the electrical board to the cabinet
• Replace the electrical board
