CPS FA1000 SERIES - Table of Contents

Unit Consists Of:
• FA1000 Series Mach 7 Automotive Refrigerant Recover / Recycling / and Recharge Machine
• 6 CFM 50 micron vacuum pump
• Recovery Cylinder - FA1000 and FA1000J inclued a 50 lb DOT storage tank, FA1000B and FA1000AB include 92 lb storage tank
FA1000E does not include storage tanks. User must use country approved storage tanks
• Low and High side service hoses for R-134a
• Low and High side R-134a couplers
• Tank rell adapter, 1/2" ACME RH Female for R-134a
• 41 cubic Inch CPS lter drier (Replacement part number ARXF5)
• Tank lter bracket with hardware and all tank hoses if the tank is not included
• 1 lb (454 gram) check weight
• Operation manual
• Models FA1000/FA1000B come with UView 481500 Oil/Dye Injection Kit, All other models come with integrated Oil Injection System
End user to provide:
• R-134a
• Refrigerant oil and/or dye for injection system
Table of Contents
Specications 2
Introduction 3
General Safety Instructions 4
Initial Equipment Preparation 5
Initial Set-Up 6
Operating Instructions 7-16
Maintenance 17-20
High Voltage Charging, Hose Maintenance and Troubleshooting Chart 21
Service Parts and Accessories 22-23
Warranty and Contact Information 23
2
FA1000 Specications
Models FA1000 / FA1000B FA1000J FA1000A / FA1000AB FA1000E
Compressor Type 2/3 HP, 2 cylinder oil-less reciprocating compressor
Dimensions 22" W x 24.5" D x 42" H
Weight
100 lbs (does not include tank weight)
Operating Range 10˚C (50˚F) to 49˚C (120˚F)
Power Source 115 VAC 60Hz 1Ph 100 VAC 50 / 60Hz 1Ph 220-240 VAC 50Hz 1Ph 220-240 VAC 50Hz 1Ph
Power Consumption 1000 W
Low Side Gauge -30 inch Hg to 125 PSIG
High Side Gauge 0 to 500 PSIG
Filtration 41 cubic inch drier, .7 micron oil separator
Automatic Control Valves Patented motorized ball valves to control HI, LO, recover, and vacuum
Charging Valve 12 VDC Solenoid Valve
Construction
1" Heavy duty tubular frame construction
10" pneumatic wheels, 4" swivel casters
Overload Protection 15A Thermal Breaker 15A Thermal Breaker 10A Thermal Breaker 10A Thermal Breaker
High Pressure Shut-O 30 bar (450 psig)
Refrigerants
R-134a
