FA1000 INITIAL SET-UP
The following instructions will guide you through the initial set up fo the unit that allows changes to operational software, language and units of
measure.
Before we power up the unit, it will be necessary to check the vacuum pump oil sight glass for the correct level. The vacuum pump is pre-lled
at the factory. Make sure the vacuum pump power switch is in the ON position. Also check the hose connecting to the vacuum pump is tight.
Make sure both Oil Injection (if equipped) and Oil Drain bottle assemblies are tight. Make sure the Oil Injection (if equipped) valve is in the
OFF
position.
Open all tank and hose valves on the back of the unit.
Plug the unit into the proper voltage power supply. Check the nameplate of the unit if there are any questions on power supply requirements.
While holding down the
Key #3
, push the momentary ON-OFF switch on the back of the unit until the LCD lights up.
SAE applies to USA use. NON-USA would be used for anywhere outside of the USA. Keep in mind the operation of the unit is slightly dierent
depending on which mode you use. Push either the
SAE or
NON-USA
key for selection. Now the laguage selection screen comes up.
Push the key next to the desired language. The LCD will now show
SELECT DEFAULT UNITS OF WEIGHT.
Push the weight measurement system
you are most likely to use.
Note: That during any Charge or Full Cycle operation, the UNIT OF WEIGHT can be temporarily changed.
The unit will proceed to the automatic PT (Pressure Transducer) calibration and then (if required) the air purge. This should only take
a few
minutes and once complete the
MAIN MENU
will appear on the LCD.
FA1000 is now ready for R-134a operation.
Place the R-134a ID tank label on the storage tank. Then go to
page 18 to ll the recovery tank with R-134a.
SELECT DEFAULT
UNITS OF
WEIGHT
LBS >
LBS : OZ >
KGS >
GRAMS >
OZ >
SELECT MODE
RECOVER >
EVACUATE >
CHARGE >
FULL CYCLE >
TANK REFILL >
The LCD comes up with
SETUP MODE
screen asking for SAE
or NON-USA.
FIGURE - 5
Key 3
SETUP MODE
SAE >
NON-USA >
SELECT DEFAULT
LANGUAGE
ENGLISH >
ESPAÑOL >
DEUTSCH >
FRANCOIS >
NEXT >
6
To Next Page
