Basic Controls
he text to know what the basic
A
. Fence Lock: Locks the fence so that
it does not move forward or backward
during any operation.
. Fence Tilt Lock: Locks the fence in
want.
TEST RUN
Once you have assembled your machine
completely, then it is time for a test run to
make sure that the machine works
properly and is ready for operation.
During the test run if there is an unusual
The basic controls of the jointer are
shown in the figure below. Use this figure
and read t
controls of your machine are.
Figure 12: Basic Controls
. On/Off button: Starts and stops the
jointer.
B
C
your desired angle so that it does not
move during the operation.
D. Table Adjustment Levers: Move the
table forward and backward.
E. Table Lock: Locks the table to the
position you
oming from the machine or the
chine vibrates, there problem might
r
2- V-belts worn or loose
new
matched set
OPERATIONS AND ADJUSTMENTS
noise c
ma
be because of the following:
1- Belts slapping cove
3- Pulley loose
4- Motor mounts loose or broken
After you investigate and if you find that
the problem with your machine is one of
the above,
1- Replace or realign the belts with a
matched set
2- Replace the belts with a
3- Realign or replace shaft, pulley,
setscrew and key
4- Tighten or replace the motor
mount
WARNING
Before starting the jointer please
make sure that you have read and
understood the manual and you are
ith the functions and safety
re to
do this may cause serious personal
familiar w
features on this machine. Failu
injury
14
