JOINTER
FEATURES
MODEL CT200-6” JOINTER WITH SPIRAL CUTTERHEAD
As part of the growing line of Craftex woodworking equipment, we are proud to offer the CT200-
6” Jointer with Spiral Cutter-Head. The Craftex name guarantees Craft Excellence. By following
the instructions and procedures laid out in this owner’s manual, you will receive years of
excellent service and satisfaction. The CT200 is a professional tool and like all power tools,
proper care and safety procedures should be adhered to.
Motor: 1 1/2 HP, 110/220 Volts, Single Phase, 15/7.5 Amps
3 ‘V’ Belts Drive.
Max. Depth of Cut – 1/8”
Max. Width of Cut – 6”
Cutter-Head Type: Spiral Cutter-Head with German Made Carbide Inserts
Cutter Head Speed: 4,850 RPM
Number of Carbide Inserts: 32
Cuts per Minute – 19,400
Table Size: 6” Width, 55 1/2 Length and Height (from floor) 32 1/2"
Die Cast Metal Cutter-Head Guard
All Ball Bearing and Cast-Iron Construction
Shielded and Lubricated Ball Bearings
Parallelogram Table Adjustment
Precision Ground Cast Iron In-feed and Out-feed
Powder Coated Body
Fence Stops: 45°,90°, 135°
Mobile Base with Locking Foot Pedal
Includes: Push Blocks and Knife Setting Jig
4” Dust Hood is included
Noise Level: Approx. 82dB
First Carton Size: 29” L x 18” W x 28” H
Second Carton Size: 62” L x 21” W x 14” H
Net Weight: 325 lbs
Warranty – 2 YEARS
5
