Craftex CT201 - Page 28

TABLE PARTS LIST
1
DJ-001
KNOB
2
DJ-002
STUD
3
DJ-003
ING BUSH
4
DJ-004
ECCENTRIC SHAFT
5
GB80
HEX SOC SET M6X16MM
SCR.
6
GB80
M8X12MM HEX SOC SET
SCR.
7
DJ-005
FENCE CARRIAGE
8
GB6170
M6 HEX NUT
9
GB5782
X BOLT M6X25 HE
10
FENCE CARRIAGE
WARNING LABEL
11
GB827
T RIVE
12
DJ-008
AR COLL
13
DJ-012
SUPPORT
14
DJ-014
5 WASHER 12.7X38X
15
GB6170
M12 HEX NUT
16
GB70
RM10X30MM SOC HD SC
17
DJ-013
WASHER 10.4X30X3
18
GB70
M5X16MM SOC HD SCR
19
DJ-009
GIB
20
DJ-010
ECCENTRIC STUD
21
DJ-011
WASHER 8.4X25X3
22
GB6170
M8 HEX NUT
23
DJ-007
SHAFT
24
GB70
0 SOC HD SCR M8X3
25
DJ-016
X16X3 WASHER 6.5
26
DJ-015
POINTER
27
GB97
Φ6MM FLAT WASHER
28
GB65
EESE HD M6X16MM CH
SCR
29
DJ-018
LOCK LEVER
30
DJ-019
INDES PIN ASSEMBLY
31
GB879
3X20MM ROLL PIN
32
DJ-020
SPRING
33
GB5782
M6X25 HEX BOLT
34
GB6170
M6 HEX NUT
35
DJ-017
SWIVEL
36
DJ-021
COLLAR
37
GB80
M8X12MM HEX SOC SET
SCR.
38
DJ-022
LOCK
39
GB80
M8X12MM HEX SOC SET
SCR.
40
DJ-023
CLAMP
41
DJ-024
THREAD CLAMP
42
DJ-025
TILT SCALE
43
GB65
M6X10MM CHEESE HD
SCR
44
GB97
Φ6MM FLAT WASHER
45
DJ-026
BALL HANDLE
46
DJ-027
STUD
47
DJ-028
FENCE
48
DJ-029
SCALE
49
GB827
RIVET
50
DJ-030B
TABLE RH
51
DJ-044B
TABLE SHAFT
52
DJ-032B
RABB
EXTE
ETING TABLE
NSION
53
GB70
M6X20MM SOC HD SCR
54
DJ-033B
CHIP DEFLECTOR
55
GB70
M6X12MM SOC HD SCR
56
GB70
M8X80MM SOC HD SCR
57
GB93
M8 LOCK WASHER
58
DJ-034B
BEARING BLOCK LH
