MODEL CX08SC - 8” JOINTER WITH MOBILE BASE
As part of the growing line of Craftex woodworking equipment, we are proud to offer the the
CX08SC, an 8” Jointer with Spiral Cutter-head. The Craftex name guarantees Craft
Excellence. By following the instructions and procedures laid out in this user manual, you will
receive years of excellent service and satisfaction. The CX08SC is a professional tool and like
all power tools, proper care and safety procedures should be adhered to.
Motor: 3 HP, 220 Volts, Single Phase, 15 Amps
3 ‘V’ Belts Drive.
Max. Depth of Cut – 1/8”
Max. Width of Cut – 8”
Cutter-Head Type: Spiral Cutter-Head with German Made Carbide Inserts
Cutter Head Speed: 5,350 RPM
Number of Carbide Inserts: 40
Cuts per Minute – 21,400
Table Size: 8” Width, 76-3/8” Length and Height (from floor) 32-5/8”
Fence Size: 1 1/4” Width, 36” Length, 5” Height, 45°, 90° and 135° Stops
Die Cast Metal Cutter-Head Guard
All Ball Bearing and Cast-Iron Construction
Shielded and Lubricated Ball Bearings
Precision Ground Cast Iron In-feed and Out-feed
Parallelogram Beds
Powder Coated Body
Mobile Base with Locking Foot Pedal
4” Dust Hood is included
First Carton Size: 81 1/2” L x 25 1/2” W x 12 1/2” H
Second Carton Size: 38” L x 18” W x 27 1/2” H
Net Weight: 510 lbs
Warranty – 3 YEARS
CX08SC – JOINTER
FEATURES
