SETUP
Before setting up your machine you should
read and understand the instructions given
in this manual.
The unpainted surfaces of this table saw
are coated with a rust preventive waxy oil
that you will want to remove before you
begin assembly. Use a solvent cleaner that
will not damage painted surfaces.
UNPACKING
The machine is properly packaged and
shipped completely in crates for safe
transportation. When unpacking, carefully
inspect the crates and ensure that nothing
has been damaged during transit. Open the
crates and check that the machine and the
parts are in good condition.
Figure-1 Inventory
LIST OF CONTENTS QTY
A. Table Saw........................................ 1
B. Extension Wings.............................. 2
C. 10” Blade ......................................... 1
D. Table Insert...................................... 1
E. Riving Knife...................................... 1
F. Spreader.......................................... 1
G. Motor Cover..................................... 1
H. Push Stick........................................ 1
Figure-2 Inventory
LIST OF CONTENTS QTY
I. Hand Wheels ................................... 2
J. Hand Wheel Locks........................... 2
K. Hand Wheel Handles....................... 2
L. Blade Guard..................................... 1
M. Miter Gauge..................................... 1
N. Scoring Blade .................................. 1
O. Hardware Bag.................................. 1
NOTE: While doing inventory, if you can not
find any part, check if the part is already
installed on the machine. Some of the parts
come preassembled with the machine
because of shipping purposes.
WARNING
CX204 is a heavy machine, do not over-
exert yourself. For safe moving method
use fork truck or get the help of an
assistant or friend.
