9
ASSEMBLY
Slide the hand wheel onto the hand wheel
shaft in front of the saw so that the tab on
the shaft is aligned with the key way on the
hand wheel. Secure it using the lock knob
provided. Thread the handle into the hole
on the hand wheel and tighten it. See
figure-4.
Figure-4 Installing the blade height hand
wheel
Install the blade tilt hand wheel on to the
shaft located on the left side of the cabinet
in the same manner. Secure it using the
lock. Thread the handle into the hole on the
hand wheel and tighten it properly. See
figure-5.
Figure-5 Installing blade tilt hand wheel
Attach the extension wings to the two sides
of the table using nuts, bolts and washers
provided. See figure-6.
Figure-6 Installing the extension wings
Place a straight-edge on the main table and
the extension wing, and make sure they are
flat with each other.
If the mating surface of the extension wing
tilts down, remove the wings and use
masking tape along the bottom edge of the
main table to shim the extension wing up.
See figure-7.
Figure-7 Using masking tape to shim the
extension wing up
