KNOWYOURDRILL-DRIVER
See Figure 1.
Beforeattemptingto use this product,familiarizeyourself
with alloperating featuresand safety rules.
BIT STORAGE
Bits provided with thedrill-drivercan be placed inthe
storagearea, located on the base of the drill.
DIRECTION OF ROTATION SELECTOR
(FORWARD/REVERSE/CENTER LOCK)
Yourdrill-driverhas a directionof rotation(forward/reverss/
centei"lock) selector located above the switch _ggar for
changing the direction of bit rotation. Setting the switch
trigger in the OFF (center lock) position helps reducethe
possibilityof accidentalstartingwhen notin use.
KEYLESS CHUCK
"me keylass chuck allows you to hand-tightenor release
the drillbit inthe chuckjaws.
LED WQRKLIGHT
The LEDworPJight,located on the front of the toolbase,
illuminateswhen the switch _'iggar ts depressed.This
providesextra light for inoreased yisibility.
LEVEL
A level is located on the top of the motor housingto help
you keepthe drill bit level duringuse;
TORQUE AI0klMSTMENT RING
Yourdrill-driverhas a 24-position clutch.The torque
adjustment ring can be turnedto selectthe rightamount
of torque for your application.
VARIABLE SPEED
The variablespeed switchtriggar delivers higher speed
with increasedttlgger pressureand lower speed with de-
,teased triggerpressure.
UNPACKING
This producthas been shipped eompiatslyassembled.
• Carefulfyremovethe tool and any accessoriesfTomthe
box. Make surethat a_litems listed in the packing list
are included.
• Inspect the too[ carefullyto make sure no breakage or
damage occurred dunng shipping.
• Do not discard the packingmaterial untilyou have
carefullyinspected and setistactoril¥ operatedthe tool.
• If any partsare damaged or missing, please call
1-800-932-3188 for ase'_tance.
PACKING UST
Drill-Driver
Battery Pack (2)
Charger
Double-ended Bits(2I
CarryingCase
Operator's Manual
,P=
41L WARNING: If anyparts are missingdo not operate
thistool untilthe missingparts arereplaced. Failure
to do socould resultin possible seriouspersonal
injury.
A
WARNING: Do not attempt to modify thistool
or createaccessories not recommended for use
with this tool. Anysuch alterationor modification is
misuse arid coutdresul_in s h_.ardous condition
leadingto possibleseriouspersonalir(|ury.
_1_ WARNING: To preventaccidental startingthat
could cause seriouspersenaf injury, a_,ays remove
the battery pack _om the too[ when assembling
parts.
