To Next PageTo Next PageWhy is my Craftsman 247.881730 engine running erratically?
Your Craftsman Snow Blower engine might run erratically due to several reasons: * The engine might be running on CHOKE. Move the choke control to the RUN position. * You might be using stale fuel. Fill the tank with clean, fresh gasoline. * There could be water or dirt in the fuel system. Drain the fuel tank by running the engine until it stops. Refill with fresh fuel.
What to do if my Craftsman 247.881730 unit fails to discharge snow?
If your Craftsman Snow Blower isn't discharging snow, consider these potential causes: * The chute assembly might be clogged. Stop the engine immediately, disconnect the spark plug wire, and clean the chute assembly and inside of the auger housing with a clean-out tool or a stick. * A foreign object could be lodged in the auger. Stop the engine immediately, disconnect the spark plug wire, and remove the object from the auger with a clean-out tool or a stick. * The auger cable may need adjustment. Adjust the auger control cable. Refer to Assembly section. * The auger belt could be loose or damaged. Replace the auger belt. Refer to Service and Maintenance section. * Shear pins might be sheared. Replace them with new shear pins.
What to do if my Craftsman 247.881730 has loss of power?
If your Craftsman Snow Blower is experiencing a loss of power: * Check if the spark plug wire is loose. Connect and tighten the spark plug wire. * Inspect the gas cap vent hole for blockage. Remove any ice and snow from the gas cap, ensuring the vent hole is clear.
What to do if my Craftsman 247.881730 unit fails to propel itself?
If your Craftsman Snow Blower isn't moving on its own, it might be because: * The drive cable needs adjustment. Adjust the drive control cable. Refer to Service and Maintenance section. * The drive belt is loose or damaged. Replace the drive belt. Refer to Service and Maintenance section. * The friction wheel is worn.
Why is my Craftsman 247.881730 Snow Blower vibrating excessively?
If your Craftsman Snow Blower is vibrating excessively, it could be due to loose parts or a damaged auger. Stop the engine immediately, disconnect the spark plug wire, and tighten all bolts and nuts.
Why chute fails to easily rotate 180 degrees on my Craftsman 247.881730?
If the chute on your Craftsman Snow Blower doesn't rotate easily, it might be assembled incorrectly. Disassemble the chute control and reassemble as directed in the Assembly section.
General| Engine | 208cc |
|---|---|
| Engine Type | 4-cycle OHV |
| Clearing Width | 24 inches |
| Intake Height | 21 inches |
| Throwing Distance | Up to 40 feet |
| Drive System | Self-propelled |
| Speed Settings | 6 forward, 2 reverse |
| Starting System | Electric start |
| Wheel Size | 13 inches |
| Chute Rotation | 200 degrees |
Instructions on reading, understanding, and following safety rules before operation.
Guidance on preparing the area and oneself before operating the machine.
Crucial safety measures for handling flammable gasoline and preventing ignition.
Warning against modifying the engine governor to prevent unsafe speeds.
Explanation of the shift lever for controlling speed and direction.
How to use the choke control for cold-weather starting.
How the throttle control regulates engine speed and stops the engine.
How the auger draws snow into the housing when engaged.
Description of snow discharge through the chute assembly.
How to engage and disengage the auger for snow throwing.
Operation of the drive control and its locking function for the auger.
How to change the direction of snow discharge using the chute control.
Step-by-step instructions for starting the engine safely.
Instructions for starting the engine manually using the recoil starter.
Procedures for safely shutting down the engine after use.
How to engage the drive system for forward or reverse motion.
Procedures for maintaining the engine, including oil and spark plugs.
How to correctly check the engine oil level.
Step-by-step guide for changing the engine oil.
Instructions for inspecting and maintaining the spark plug.
Common causes and remedies for engine starting issues.
Troubleshooting steps for inconsistent engine performance.
