Crane BARNES SITHE 4SCD Series - Page 10

10
MODEL
NO
HP VOLT PH Hz
RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
SITHE SCDU Pump
8SCDU25094 25.0
208
3 60 1750 G
77.8
1.2
93.4
359.0 138319 2/4 - 18/4 1.47 ± .03 .098
230 71.4 82.3
8SCDU30094 30.0
208
3 60 1750 E
93.4 1.2 116.9
359.0 138319 2/4 - 18/4 1.47 ± .03 .098
230 82.3 1.2 98.7
8SCDU40034 40.0 230 3 60 1750 E 106.0 1.2 126.4 486.0 138319 2/4 - 18/4 1.47 ± .03 .063
8SCDU40044 40.0 460 3 60 1750 E 53.0 1.2 63.2 243.0 138318 6/4 - 18/4 1.14 ± .03 .248
8SCDU40054 40.0 575 3 60 1750 E 42.4 1.2 50.6 194.4 138317 8/4 - 18/4 1.12 ± .02 .382
8SCDU50044 50.0 460 3 60 1750 F 67.1 1.2 79.0 339.0 138318 6/4 - 18/4 1.14 ± .03 .15
8SCDU50054 50.0 575 3 60 1750 F 53.7 1.2 63.2 271.2 138318 6/4 - 18/4 1.14 ± .03 .245
8SCDU60044 60.0 460 3 60 1750 E 79.0 1.2 95.5 339.0 138319 2/4 - 18/4 1.47 ± .03 .15
8SCDU60054 60.0 575 3 60 1750 E 63.2 1.2 76.4 271.2 138318 6/4 - 18/4 1.14 ± .03 .245
8SCDU20096 20.0
208
3 60 1150 H
60.3 1.2 71.5
354.0 138318 6/4 - 18/4 1.14 ± .03 .1117
230 57.2 1.2 69.8
8SCDU25096 25.0
208
3 60 1150 G
75.2 1.2 90.8
354.0 138319 2/4 - 18/4 1.47 ± .03 .1117
230 70.8 1.2 82.6
8SCDU25046 25.0 460 3 60 1150 G 35.4 1.2 41.3 177.0 138317 8/4 - 18/4 1.12 ± .02 .4397
8SCDU25056 25.0 575 3 60 1150 G 28.3 1.2 33.0 141.6 138317 8/4 - 18/4 1.12 ± .02 .6857
8SCDU7598 7.5
208
3 60 870 L
32.0
1.2
35.0
230.0 138317 8/4 - 18/4 1.12 ± .02 .199
230 34.6 36.9
8SCDU7548 7.5 460 3 60 870 L 17.3 1.2 18.5 115.0 138317 8/4 - 18/4 1.12 ± .02 .795
8SCDU7658 7.5 575 3 60 870 L 13.9 1.2 14.8 92.0 138317 8/4 - 18/4 1.12 ± .02 1.27
8SCDU10098 10.0
208
3 60 870 L
37.2
1.2
42.0
230.0 138317 8/4 - 18/4 1.12 ± .02 .199
230 38.6 42.2
8SCDU10048 10.0 460 3 60 870 L 19.3 1.2 21.1 115.0 138317 8/4 - 18/4 1.12 ± .02 .795
8SCDU10058 10.0 575 3 60 870 L 15.4 1.2 16.9 92.0 138317 8/4 - 18/4 1.12 ± .02 1.27
8SCDU15098 15.0
208
3 60 870 G
50.4
1.2
59.0
230.0 138317 8/4 - 18/4 1.12 ± .02 .199
230 48.4 55.6
8SCDU15048 15.0 460 3 60 870 G 24.2 1.2 27.8 115.0 138317 8/4 - 18/4 1.12 ± .02 .795
8SCDU15058 15.0 575 3 60 870 G 19.4 1.2 22.2 92.0 138317 8/4 - 18/4 1.12 ± .02 1.27
Moisture and Temperature sensor leads are integral to power cord. Winding Resistance ± 7.5% Winding resistance measured in OHMS @ 25°C (Between Lines) at motor leads. Pump rated for operation at ± 10% voltage at motor. ▲ Cord Sufx: XF - 50 Feet, XJ - 75 Feet, or XL - 100 Feet
▲ Cord sold separately.
CHART ‘E’
