CHART ‘F’
MODEL
NO
HP VOLT PH Hz
RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
SITHE SCTM Pump
8SCTM60044 60.0 460 3 60 1750 E 79.0 1.2 95.5 339.0 138319 2/4 - 18/4 1.47 ± .03 .15
8SCTM60054 60.0 575 3 60 1750 E 63.2 1.2 76.4 271.2 138318 6/4 - 18/4 1.14 ± .03 .245
8SCTM20096* 20.0
208
3 60 1150 H
60.3 1.2 71.5
354.0 138318 6/4 - 18/4 1.14 ± .03 .3277
230 57.2 1.2 69.8
8SCTM25096 25.0
208
3 60 1150 G
75.2 1.2 90.8
354.0 138319 2/4 - 18/4 1.47 ± .03 .1117
230 70.8 1.2 82.6
8SCTM25046 25.0 460 3 60 1150 G 35.4 1.2 41.3 177.0 138317 8/4 - 18/4 1.12 ± .02 .4397
8SCTM25056 25.0 575 3 60 1150 G 28.3 1.2 33.0 141.6 138317 8/4 - 18/4 1.12 ± .02 .6857
8SCTM30096 30.0
208
3 60 1150 E
90.8 1.2 114.9
354.0 138319 2/4 - 18/4 1.47 ± .03 .1117
230 82.6 1.2 99.7
8SCTM30046 30.0 460 3 60 1150 E 41.3 1.2 49.9 177.0 138317 8/4 - 18/4 1.12 ± .02 .4397
8SCTM30056 30.0 575 3 60 1150 E 33.0 1.2 39.9 141.6 138317 8/4 - 18/4 1.12 ± .02 .6857
8SCTM40036 40.0 230 3 60 1150 E 110.4 1.2 131.8 476.0 138319 2/4 - 18/4 1.47 ± .03 .0819
8SCTM40046 40.0 460 3 60 1150 E 55.2 1.2 65.9 238.0 138318 6/4 - 18/4 1.14 ± .03 .3277
8SCTM40056 40.0 575 3 60 1150 E 44.2 1.2 52.7 190.4 138317 8/4 - 18/4 1.12 ± .02 .5443
Moisture and Temperature sensor leads are integral to power cord. Winding Resistance ± 7.5% Winding resistance measured in OHMS @ 25°C (Between Lines) at motor leads. Pump rated for operation at ± 10% voltage at motor. ▲ Cord Sufx: XF - 50 Feet, XJ - 75 Feet, or XL - 100 Feet
▲ Cord sold separately.
