Crane BARNES SITHE 4SCD Series - Page 12

12
MODEL
NO
HP VOLT PH Hz
RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
SITHE SCTM Pump
8SCTM7598* 7.5
208
3 60 870 L
32.0
1.2
35.0
230.0 138317 8/4 - 18/4 1.12 ± .02 .199
230 34.6 36.9
8SCTM7548* 7.5 460 3 60 870 L 17.3 1.2 18.5 115.0 138317 8/4 - 18/4 1.12 ± .02 .795
8SCTM7658* 7.5 575 3 60 870 L 13.9 1.2 14.8 92.0 138317 8/4 - 18/4 1.12 ± .02 1.27
8SCTM10098 10.0
208
3 60 870 L
37.2
1.2
42.0
230.0 138317 8/4 - 18/4 1.12 ± .02 .199
230 38.6 42.2
8SCTM10048 10.0 460 3 60 870 L 19.3 1.2 21.1 115.0 138317 8/4 - 18/4 1.12 ± .02 .795
8SCTM10058 10.0 575 3 60 870 L 15.4 1.2 16.9 92.0 138317 8/4 - 18/4 1.12 ± .02 1.27
8SCTM15098 15.0
208
3 60 870 G
50.4
1.2
59.0
230.0 138317 8/4 - 18/4 1.12 ± .02 .199
230 48.4 55.6
8SCTM15048 15.0 460 3 60 870 G 24.2 1.2 27.8 115.0 138317 8/4 - 18/4 1.12 ± .02 .795
8SCTM15058 15.0 575 3 60 870 G 19.4 1.2 22.2 92.0 138317 8/4 - 18/4 1.12 ± .02 1.27
8SCTM20098 20.0
208
3 60 870 J
69.0
1.2
76.0
400.0 138318 6/4 - 18/4 1.14 ± .03 .121
230 75.1 79.0
8SCTM20048 20.0 460 3 60 870 J 37.6 1.2 41.1 200.0 138317 8/4 - 18/4 1.12 ± .02 .483
8SCTM20058 20.0 575 3 60 870 J 30.1 1.2 32.9 160.0 138317 8/4 - 18/4 1.12 ± .02 .77
8SCTM25098 25.0
208
3 60 870 H
82.3
1.2
98.8
400.0 138319 2/4 - 18/4 1.47 ± .03 .121
230 84.0 94.5
8SCTM25048 25.0 460 3 60 870 H 42.0 1.2 47.2 200.0 138317 8/4 - 18/4 1.12 ± .02 .483
8SCTM25058 25.0 575 3 60 870 H 33.6 1.2 37.8 160.0 138317 8/4 - 18/4 1.12 ± .02 .77
8SCTM30098 30.0
208
3 60 870 F
98.8
1.2
124.1
400.0 138319 2/4 - 18/4 1.47 ± .03 .121
230 94.5 108.6
8SCTM30048 30.0 460 3 60 870 F 47.2 1.2 54.3 200.0 138317 8/4 - 18/4 1.12 ± .02 .483
8SCTM30058 30.0 575 3 60 870 F 37.8 1.2 43.5 160.0 138317 8/4 - 18/4 1.12 ± .02 .77
Moisture and Temperature sensor leads are integral to power cord. Winding Resistance ± 7.5% Winding resistance measured in OHMS @ 25°C (Between Lines) at motor leads. Pump rated for operation at ± 10% voltage at motor. ▲ Cord Sufx: XF - 50 Feet, XJ - 75 Feet, or XL - 100 Feet
▲ Cord sold separately.
