Crane BARNES SITHE 4SCD Series - Page 13

13
MODEL
NO
HP VOLT PH Hz
RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
SITHE SCDW Pump
10SCDW25096 25.0
208
3 60 1150 G
75.2 1.2 90.8
354.0 138319 2/4 - 18/4 1.47 ± .03 .1117
230 70.8 1.2 82.6
10SCDW25046 25.0 460 3 60 1150 G 35.4 1.2 41.3 177.0 138317 8/4 - 18/4 1.12 ± .02 .4397
10SCDW25056 25.0 575 3 60 1150 G 28.3 1.2 33.0 141.6 138317 8/4 - 18/4 1.12 ± .02 .6857
10SCDW30096 30.0
208
3 60 1150 E
90.8 1.2 114.9
354.0 138319 2/4 - 18/4 1.47 ± .03 .1117
230 82.6 1.2 99.7
10SCDW30046 30.0 460 3 60 1150 E 41.3 1.2 49.9 177.0 138317 8/4 - 18/4 1.12 ± .02 .4397
10SCDW30056 30.0 575 3 60 1150 E 33.0 1.2 39.9 141.6 138317 8/4 - 18/4 1.12 ± .02 .6857
10SCDW40036 40.0 230 3 60 1150 E 110.4 1.2 131.8 476.0 138319 2/4 - 18/4 1.47 ± .03 .0819
10SCDW40046 40.0 460 3 60 1150 E 55.2 1.2 65.9 238.0 138318 6/4 - 18/4 1.14 ± .03 .3277
10SCDW40056 40.0 575 3 60 1150 E 44.2 1.2 52.7 190.4 138317 8/4 - 18/4 1.12 ± .02 .5443
10SCDW10098 10.0
208
3 60 870 L
37.2
1.2
42.0
230.0 138317 8/4 - 18/4 1.12 ± .02 .199
230 38.6 42.2
10SCDW10048 10.0 460 3 60 870 L 19.3 1.2 21.1 115.0 138317 8/4 - 18/4 1.12 ± .02 .795
10SCDW10058 10.0 575 3 60 870 L 15.4 1.2 16.9 92.0 138317 8/4 - 18/4 1.12 ± .02 1.27
10SCDW15098 15.0
208
3 60 870 G
50.4
1.2
59.0
230.0 138317 8/4 - 18/4 1.12 ± .02 .199
230 48.4 55.6
10SCDW15048 15.0 460 3 60 870 G 24.2 1.2 27.8 115.0 138317 8/4 - 18/4 1.12 ± .02 .795
10SCDW15058 15.0 575 3 60 870 G 19.4 1.2 22.2 92.0 138317 8/4 - 18/4 1.12 ± .02 1.27
10SCDW20098 20.0
208
3 60 870 J
69.0
1.2
76.0
400.0 138318 6/4 - 18/4 1.14 ± .03 .121
230 75.1 79.0
10SCDW20048 20.0 460 3 60 870 J 37.6 1.2 41.1 200.0 138317 8/4 - 18/4 1.12 ± .02 .483
10SCDW20058 20.0 575 3 60 870 J 30.1 1.2 32.9 160.0 138317 8/4 - 18/4 1.12 ± .02 .77
10SCDW25098 25.0
208
3 60 870 H
82.3
1.2
98.8
400.0 138319 2/4 - 18/4 1.47 ± .03 .121
230 84.0 94.5
10SCDW25048 25.0 460 3 60 870 H 42.0 1.2 47.2 200.0 138317 8/4 - 18/4 1.12 ± .02 .483
10SCDW25058 25.0 575 3 60 870 H 33.6 1.2 37.8 160.0 138317 8/4 - 18/4 1.12 ± .02 .77
Moisture and Temperature sensor leads are integral to power cord. Winding Resistance ± 7.5% Winding resistance measured in OHMS @ 25°C (Between Lines) at motor leads. Pump rated for operation at ± 10% voltage at motor. ▲ Cord Sufx: XF - 50 Feet, XJ - 75 Feet, or XL - 100 Feet
▲ Cord sold separately.
CHART ‘G’
