Crane BARNES SITHE 4SCD Series - Page 14

14
CHART ‘H’
MODEL
NO
HP VOLT PH Hz
RPM
(Nom)
NEMA
START
CODE
FULL
LOAD
AMPS
SERVICE
FACTOR
SERVICE
FACTOR
AMPS
LOCKED
ROTOR
AMPS
CORD
P/N ▲
CORD
SIZE
CORD
O.D.
WINDING
RESISTANCE
SITHE SCDX Pump
10SCDX40036 40.0 230 3 60 1150 E 110.4 1.2 131.8 476.0 138319 2/4 - 18/4 1.47 ± .03 .819
10SCDX40046 40.0 460 3 60 1150 E 55.2 1.2 65.9 238.0 138318 6/4 - 18/4 1.14 ± .03 .3277
10SCDX40056 40.0 575 3 60 1150 E 44.2 1.2 52.7 190.4 138317 8/4 - 18/4 1.12 ± .02 .5443
10SCDX15098 15.0
208
3 60 870 G
50.4
1.2
59.0
230.0 138317 8/4 - 18/4 1.12 ± .02 .199
230 48.4 55.6
10SCDX15048 15.0 460 3 60 870 G 24.2 1.2 27.8 115.0 138317 8/4 - 18/4 1.12 ± .02 .795
10SCDX15058 15.0 575 3 60 870 G 19.4 1.2 22.2 92.0 138317 8/4 - 18/4 1.12 ± .02 1.27
10SCDX20098 20.0
208
3 60 870 J
69.0
1.2
76.0
400.0 138318 6/4 - 18/4 1.14 ± .03 .121
230 75.1 79.0
10SCDX20048 20.0 460 3 60 870 J 37.6 1.2 41.1 200.0 138317 8/4 - 18/4 1.12 ± .02 .483
10SCDX20058 20.0 575 3 60 870 J 30.1 1.2 32.9 160.0 138317 8/4 - 18/4 1.12 ± .02 .77
10SCDX25098 25.0
208
3 60 870 H
82.3
1.2
98.8
400.0 138319 2/4 - 18/4 1.47 ± .03 .121
230 84.0 94.5
10SCDX25048 25.0 460 3 60 870 H 42.0 1.2 47.2 200.0 138317 8/4 - 18/4 1.12 ± .02 .483
10SCDX25058 25.0 575 3 60 870 H 33.6 1.2 37.8 160.0 138317 8/4 - 18/4 1.12 ± .02 .77
10SCDX30098 30.0
208
3 60 870 F
98.8
1.2
124.1
400.0 138319 2/4 - 18/4 1.47 ± .03 .121
230 94.5 108.6
10SCDX30048 30.0 460 3 60 870 F 47.2 1.2 54.3 200.0 138317 8/4 - 18/4 1.12 ± .02 .483
10SCDX30058 30.0 575 3 60 870 F 37.8 1.2 43.5 160.0 138317 8/4 - 18/4 1.12 ± .02 .77
Moisture and Temperature sensor leads are integral to power cord. Winding Resistance ± 7.5% Winding resistance measured in OHMS @ 25°C (Between Lines) at motor leads. Pump rated for operation at ± 10% voltage at motor. ▲ Cord Sufx: XF - 50 Feet, XJ - 75 Feet, or XL - 100 Feet
▲ Cord sold separately.
