SC 28 Frame - PARTS LIST
Rotor Kit ............................See Table on Page 37
(◊) 36
Stator Kit ........................... See Table on Page 37 (≈) 28, 30, 35, 38, 52, 58, 62
Seal Kit .............................. See Table on Page 35 (+) 4A, 4B, 7, 9, 9A, 9B, 19, 53, 56
Bearing Kit .......................................... p/n 138578 (●) 16, 17, 18, 20
Hardware Kit ....................................... p/n 138617 (♦) 2, 8, 8A, 13, 15, 34, 52
Volute Kit ........................... See Table on Page 25 (■) 10, 11, 62
Seal Plate Kit ..................... See Table on Page 25 (‡) 3, 14, 39, 62
Bearing Bracket Kit .......................p/n 138612-16 (◘) 14, 47, 62
Terminal Block Kit .........................p/n 138595-16 (§) 25, 52, 53, 54, 55
Moisture Sensor Kit ............................ p/n 138613 (−) 24, 27, 37, 51
Slicer Blade Attach. Kit .... See Table on Page 38 (○) 8, 8A
Motor Cap Kit ................................. p/n 139237-16 (£) 14, 34, 40, 57, 62
Leg Kit ............................... See Table on Page 36
Removeable Cord Assy ... See Table on Page 24 (β) 8, 56, 59, 62
Cord Attachment Kit ......................p/n 140152-32 (π) 8, 56
Slicer Blade Kit ................. See Table on Page 28 (∂) 6, 6A, 6B
Shim Kit ............................. See Table on Page 26 (∆) 64
Striker Plate Kit ................. See Table on Page 26 (∑) 63, 64, 65, 66
Striker Shell Kit ................. See Table on Page 26 (⌂) 62, 63, 64, 65, 66
Striker Hardware Kit ......... See Table on Page 26 (∩) 65, 66
Striker O-Ring Stock Kit ..................... p/n 142635 (▲) 66
ITEM QTY PART NO. DESCRIPTION MATERIAL
2 8 127223 ♦ Screw, SHCS, M12 x 1.75 x 25 300 SS
3 1 127248 ‡ Pin, Spring, .125 Dia. x .50” LG, SS 420 SS
4A 1 129900 + Seal, Mech-type 21, 1.875” C/CE/B
4B 1 129900SD + Seal, Mech-type 21, 1.875” SC/SC/B
6 1 See Table ∂ Impeller Ductile Iron
6A 1 See Table ∂ Slicer Blade Stainless 440C
6B 4 See Table ∂ Slicer Pins Stainless 400
7 1 Q21-20-J8 + Key, ¼ x ¼ x 1½”, 303 SS 303 SS
8 5 136284 ♦ ○ βπ Screw, SHCS, M12 x 1.75 x 30 18-8 SS
8A 1 136233 ♦ ○ Washer, Impeller, .50 x 1.50 18-8 SS
9 1 See Table + O-Ring (Volute) Buna-N
9A 2 125857-295 + O-Ring, M3 x 295mm, 70 DURO Buna-N
9B 2 125857-265 + O-Ring, M3 x 265, 70 DURO Buna-N
10 1 See Table ■ ⌂ Volute Cast Iron
11 See Table ■ ⌂ Wear Ring (Volute) Bronze
13 4 125850 ♦ Screw, SFHCS, M10 x 1.5 x 20 18-8 SS
14 3 014270-SS ‡◘ £ Plug, Pipe, .375-18NPT, C’Sunk 300 SS
15 28 131147 ♦ Screw, SHCS, M10 x 1.5 x 35, SS ASTM A193
16 1 127274 ● Bearing, Ball, 6306
17 1 51939 ● Bearing, Ball, 3310-A
18 1 127271 ● Washer, Spring, Wavy, 72mm, STL Carbon Steel
19 2 130063 + Ring, Retaining, EXT, 5100-187-HPH SS
20 1 130073 ● Ring, Retaining, 5000-433-H, SS SS
24 2 125856 − Sensor, Moisture, .250-18NPT, AMP PP / SS
25 1 138175 § Block, Terminal, 9 Pin, Male Valox/Brass
26 1 138550 Single Sale Handle, Lifting, SS 304 SS
27 1 127267 − Resistor, Moisture, Sensor
28 1 138545 ≈ Pin, Dowel, 7/16” D, 5/8” LG AISI 1020
30 1 127269 ≈ Plug, Pipe, .250-18 NPT, SS 300 SS
34 1 125855 ♦ £ Screw, SHCS, M5 x .8 x 8, SS 300 SS
35 1 See Chart ≈ Stator
