Crane BARNES SITHE 4SCD Series - Page 25

25
36 1 See Chart ◊ Rotor
37 2 127234 − Wire, Jumper, Blue, 24” Bar/Bar
38 1 130711 ≈ Housing, Motor, Lower, 280Fr Class 30 CI
39 1 See Chart ‡ Plate, Seal Ductile Iron
40 1 138180 £ Cap, Motor Class 30 CI
47 1 130713 ◘ Bracket, Bearing, 28Fr Class 30 CI
51 2 134013 − Connector, Wire, Clip PC
52 3 138542 ≈ ♦ § Screw, SHCS/SF, M8 x 1.25 x 12 Steel
53 1 625-01551 + § O-Ring, 2-232, Buna-N, 70 Duro Buna-N
54 1 138547 § Pin, Dowel, .313” x 1.25” LG, SS 18-8 SS
55 1 138549 § Ring, Retaining, Terminal Block Steel
56 1 2-31003-248 + βπ O-Ring, Cord, Attachment Buna-N
57 4 1628 £ Rivet, Name Plate 300 SS
58 1 127266S ≈ Plate, Model SS
59 1 See Table β Cord See Table
60 2 39462 Tie, Cable, Self-clinching
61 29034 No Resale Oil Fill Oil
62 Paint ≈ ■‡◘ £β ⌂ Epoxy Paint
63 1 See Table ∑⌂ Striker Plate Stainless 440C
64 * See Table ∆∑⌂ Shims
65 ** 131147 ∑⌂∩ Striker Plate Screw, SHCS, M10 x 1.5 x 35 18-8 Stainless Steel
66 1 See Table ∑⌂∩▲ Striker, O-Ring, Buna-N, 70 Duro Buna-N
NOTES:
* Quantity dependent on Blade clearance, nominal is 0.09 Shim Stack, with 0.003 gap between Blade and Plate.
** See Table for Quantity.
SC 28 Frame - PARTS LIST
ITEM QTY PART NO. DESCRIPTION MATERIAL
'Plug and Play' (Removeable) Cord Assemblies
Part No.
Length
(feet)
Cord Size Cord O.D.
138317XF 50 8/4 - 18/4 1.12in ± .02in (28.4mm ± .5mm)
138317XJ 75 8/4 - 18/4 1.12in ± .02in (28.4mm ± .5mm)
138317XL 100 8/4 - 18/4 1.12in ± .02in (28.4mm ± .5mm)
138318XF 50 6/4 - 18/4 1.14in ± .03in (28.9mm ± .8mm)
138318XJ 75 6/4 - 18/4 1.14in ± .03in (28.9mm ± .8mm)
138318XL 100 6/4 - 18/4 1.14in ± .03in (28.9mm ± .8mm)
138319XF 50 2/4 - 18/4 1.47in ± .03in (37.3mm ± .8mm)
138319XJ 75 2/4 - 18/4 1.47in ± .03in (37.3mm ± .8mm)
138319XL 100 2/4 - 18/4 1.47in ± .03in (37.3mm ± .8mm)
138320XF 50 0/4 - 18/5
1.72in ± .03in (43.7mm ± .8mm)
.47in ± .02in (12mm ± .5mm)
138320XJ 75 0/4 - 18/5
1.72in ± .03in (43.7mm ± .8mm)
.47in ± .02in (12mm ± .5mm)
138320XL 100 0/4 - 18/5
1.72in ± .03in (43.7mm ± .8mm)
.47in ± .02in (12mm ± .5mm)
* All Assemblies include cord, grommets, and housing in a potted assembly.
Removeable Cord Attachment Kit includes:
• O-ring Cord
• Attachment Bolts
