Crane BARNES SITHE 4SCD Series - Page 38

38
Additional Components
Component Part No. Single Sale Kit
Impeller See Table Yes N/A
Wear Rings See Table Yes Volute Kit, Volute Kit
Lifting Handle 125458 Yes N/A
Pipe Plugs 014270-SS, 127269 Yes
Seal Plate Kit, Stator Kit,
Bearing Bracket Kit
Wire Tie Cable 039462 Yes Stator Kit
Nameplate No Resale
Nameplate/Model Plate Rivets 001628 No Resale Rivet Kit (p/n 139398)
Driver Assembly
Purchase:
Stator Kit, Rotor Kit, Seal Kit, Bearing Kit, Bearing Bracket Kit,
Hardware Kit, Seal Plate Kit, Terminal Block Kit
Upper Motor Housing Cap 139236 (KIT) Kit Only Upper Motor Housing Kit
Overhaul Kit Purchase Seal Kit and Hardware Kit
Leg Kit includes:
• 3 Legs (painted)
• attachement hardware
Leg Kits
Model
Leg Kit
Part No.
Leg Kit Height
Inches (mm)
3SCMPA 125506 3.15 (80)
4SCMS 125506 3.15 (80)
4SCDF 125506 3.15 (80)
4SCMC 125506 3.15 (80)
4SCDG 125506 3.15 (80)
4SCMD 125506B 6.50 (165)
6SCDO 125506B 6.50 (165)
4SCMB 125506B 6.50 (165)
4SCME 125506B 6.50 (165)
4SCMEA 125506B 6.50 (165)
4SCDI 125506B 6.50 (165)
6SCMN 125506B 6.50 (165)
6SCMH 125506B 6.50 (165)
6SCMJ 125506B 6.50 (165)
6SCDK 125506B 6.50 (165)
8SCDU 125506B 6.50 (165)
8SCTM 125506C 10.75 (273)
10SCDW 125506C 10.75 (273)
10SCDX 125506C 10.75 (273)
