Crane BARNES SITHE 4SCD Series - Page 39

39
1750 RPM
Model No.
Rotor Kit
Part No.
Stator / Motor Housing
Kit Part No.
─ SC ─ ─ 20064 131998 132074
─ SC ─ ─ 25094 131999 132075
─ SC ─ ─ 30034 138653 138654
─ SC ─ ─ 30094 138725 138733
─ SC ─ ─ 40034 132122 132130
─ SC ─ ─ 40044 138727 138734
─ SC ─ ─ 40054 138728 132132
─ SC ─ ─ 40094 138651 138652
─ SC ─ ─ 50044 132000 132076
─ SC ─ ─ 50054 132001 132077
─ SC ─ ─ 60044 132002 132078
─ SC ─ ─ 60054 132003 132079
1150 RPM
Model No.
Rotor Kit
Part No.
Stator / Motor Housing
Kit Part No.
─ SC ─ ─ 20096 132923 132941
─ SC ─ ─ 25096 132924 132942
─ SC ─ ─ 25046 132925 132943
─ SC ─ ─ 25056 132926 132944
─ SC ─ ─ 30096 132927 132945
─ SC ─ ─ 30046 132928 132946
─ SC ─ ─ 30056 132929 132947
─ SC ─ ─ 40036 138739 132948
─ SC ─ ─ 40046 132931 132949
─ SC ─ ─ 40056 132932 132950
Stator/Motor Housing Kit includes:
• Motor Housing (painted)
• Stator
• Dowel Pin (Replaces Pin Spring)
• Small Pipe Plug
• Motor Plate
• Self-clinching Tie Cable
• Model Plate Rivets
Example
Model No.
Rotor Kit
Part No.
Stator / Motor
Housing Kit Part
No.
6SCMH50044 132000 132076
Rotor Kit includes:
• Rotor
870 RPM
Model No.
Rotor Kit
Part No.
Stator / Motor Housing
Kit Part No.
─ SC ─ ─ 7598 145154 145157
─ SC ─ ─ 7598 145155 145158
─ SC ─ ─ 7598 145156 145159
─ SC ─ ─ 10098 140157 140175
─ SC ─ ─ 10048 140158 140176
─ SC ─ ─ 10058 140159 140177
─ SC ─ ─ 15098 140160 140178
─ SC ─ ─ 15048 140161 140179
─ SC ─ ─ 15048 140162 140180
─ SC ─ ─ 20098 140163 140181
─ SC ─ ─ 20048 140164 140182
─ SC ─ ─ 20058 140165 140183
─ SC ─ ─ 25098 140166 140184
─ SC ─ ─ 25048 140167 140185
─ SC ─ ─ 25058 140168 140186
─ SC ─ ─ 30098 140169 140187
─ SC ─ ─ 30048 140170 140188
─ SC ─ ─ 30058 140171 140189
