GENERAL INFORMATION
VENDER SAFETY PRECAUTIONS
Please read this manual in its entirety. This service information is intended for use by a qualified service technician
who is familiar with proper and safe procedures to be followed when repairing, replacing or adjusting any Crane
Merchandising Systems vendor components. A qualified service technician, who is equipped with the proper
tools and replacement components, using genuine Crane Merchandising Systems factory parts, should perform
all repairs. Those individuals that have a clear understanding of how to operate a vending machine in a safe
manner should only use this Vendor.
REPAIRS AND/OR SERVICING ATTEMPTED BY UNQUALIFIED PERSONS CAN RESULT IN
HAZARDS DEVELOPING DUE TO IMPROPER ASSEMBLY OR ADJUSTMENTS WHILE
PERFORMING SUCH REPAIRS. PERSONS NOT HAVING A PROPER BACKGROUND MAY
SUBJECT THEMSELVES TO THE RISK OF INJURY OR ELECTRICAL SHOCK WHICH CAN
BE SERIOUS OR EVEN FATAL.
PRODUCT IDENTIFICATION
First production of BevMax 4 5800-4/3800-4 Domestic and BevMax 4 5800-E4/3800-E4 Export Venders with new
electronics platform was August 2020. The production date of Crane Merchandising Systems products is now
determined by the date code incorporated in the serial number.
The Machine serial number incorporates the build date, in the format:
11yymmddxxxx
11 indicates the BevMax model, yymmdd is the year, month, & date of production, and xxxx is a sequential build
number.
CE Mark & IIA DECLARATION
An updated CE Mark or IIA Declaration document can be provided upon request: If needed please contact
Technical Support Manager in Williston, SC. By email service@cranems.com.
PHYSICAL CHARACTERISTICS
5800-4
5800-E4
5800-4HC
3800-4
3800-E4
3800-4HC
HEIGHT
72” (182.88 cm)
72” (182.88 cm)
WIDTH
47” (119.38 cm)
39” (99.06 cm)
DEPTH CABINET
32” (81.28 cm)
32” (81.28 cm)
DEPTH WITH SERVICE
DOOR
33.5” (85.09 cm)
33.5” (85.09 cm)
BASE
3.5” (8.89 cm)
3.5” (8.89 cm)
SHIPPING WEIGHT
764 lbs.
(346.54 kg)
675 lbs.
(306.17 kg)
Noise Level
Operates at < 70db.
Glass door width is 37.5” (95.25 cm) 5800’s, 28.1” (71.37 cm) 3800’s,
height is 68” (172.72 cm) both.

Crane BevMAX Refresh 4 3800-4HC Specifications

General

Brand	Crane
Model	BevMAX Refresh 4 3800-4HC
Category	Vending machines
Language	English
