Section 8 - Dispense Pipe Lengths
There are three sizes of pipe used on a COTI machine which can be replaced by the Operator:
CoEx Espresso Brewer = 4mm white silicone
CoEx Brewer - non espresso and Oltre Fresh Brew Brewer = 8mm grey silicone
All others = 6mm grey silicone
To replace pipes:
1. Open cabinet door and extend the delivery head by pressing 8 on the service keypad.
2. Using the above information about pipe size connect the pipes to the dispense head;
the numbers on the diagram below indicate which mixing bowl/brewer should be
connected to which nozzle.
3. The pipes should be cut to such lengths that when the head is in this extended
position they are not too taut and neither does the pipe sag below the delivery head.
