Appendices
General Specifications ......................................................................................... A-1
Changing Hardware Settings .............................................................................. B-1
A Closer Look at Your Hardware Settings ................................................
B-1
Changing Configuration
of
Jumpers ......................................................... B-2
Changing the Settings ............................................................................... B-3
Changing Base 1/0 Address
of
Audio Interface ........................... B-3
Changing the IRQ Line
of
Audio Interface .................................. B-4
Changing the OMA Channel
of
Audio Interface .......................... B-5
Enabling/Disabling OMA Sharing ............................................... B-6
Enabling/Disabling Joystick Port ................................................. B-6
Running the Configuration Utility ...........................................................
13-
7
Setting Environment Variables ........................................................................... C-1
SOUND Environment Variable ................................................................
C-1
BLASTER Environment Variable ............................................................
C-1
MIDI Environment Variable .................................................................... C-2
A Closer Look at Your Internal Device Connectors .........................................
D-1
CD In Connector Pin Assignments ..............................................
D-1
PC Spk Connector Pin Assignments ............................................
D-2
Audio Extension Connector Pin Assignments ............................. D-2
Redirecting PC Sounds to External Speakers ..............................
D-3
Troubleshooting ...................................................................................................
E-1
Problems in DOS ......................................................................................
E-1
Problems in Windows ............................................................................... E-2
Problems with the Joystick ........................................................................ E-2
Problems with Sound ................................................................................
E-3
Resolving Hardware Conflicts ..................................................................
E-3
Technical Support ................................................................................................
F-1
IV
Introduction
Congratulations on your purchase
of
our 8-bit audio card. With this card.
you now have the capability to record and playback 8-bit digitized stereo
audio. The built-in Mixer plus the external Volume Control Knob let you
adjust the volume settings
of
your audio source to a level you desire. In
addition, your audio card allows you to connect a Creative
CD-ROM
drive
for endless hours
of
multimedia fun.
Before
You
Begin
Before you begin setting up your package, you should read the following
carefully:
0 Checking System Requirements
0 Obtaining Latest Information
0 Making a Backup
0 Using this Guide
0 Document Conventions
Checking
System
Requirements
You need to verify that your system meets the following requirements:
0 IBM 286, 386, 486,
or
100% compatibles.
0 EGA or VGA card (VGA recommended).
0 4 MB
of
hard-disk space for the software.
0 Windows 3.1 for Windows applications.
Obtaining
Latest
Information
The README file on your audio diskette contains the latest information
and changes not available at the time
of
printing. Please read the file
before you continue. To view the file, insert the diskette in your disk drive
and enter
README.
