Overview
1. NFC Receptor
2. Battery Indicator
3. Record Indicator
4. Power /
Bluetooth
®
Status Indicator
5. Multifunction Button
6. Volume Up / Down Button
7. Button
8. Power ON / Standby Button
9. Microphone
10. DC Input
11. Aux-in / MegaStereo Feature
12. DC Out (USB 1.0A)
13. Micro USB Connector
14. MicroSD Slot
15. Mic On / Mute Switch
16. Record Button
17. (Record) Play / Pause Button
18. Shuffle / Repeat All Switch
19. Previous Button
20. Next Button
21. (MP3 Playback) Play / Pause Button
22. Link Security Mode switch
23. Alarm / TeraBass Mode Button
24. (Alarm) Arm / Off Switch
Top Rear
7
8
1 3 4
2 5
6
9
11
12
13
14
10
15
17
18
20
22
24
16
19
21
23
