4
Battery positive side up
2
1
3
IMPORTANT: Before replacing the battery ensure the heater is isolated from the electricity
supply. NOTE - Battery should be disposed of in an appropriate manner
Battery Replacement
This product is fi tted with a replaceable battery in the controls. To replace the battery, follow
the steps below, shown in Fig. 5:
1. Unhinge the heater from the wall using the clips shown in Fig. 2 and locate the battery module
2. Slide the catch and pull module from the controls.
3.
Remove the coin cell battery and replace with a new 3.3V type CR2032, T85°C coin cell battery.
4. Slide module back in place, ensuring clip is engaged.
Fig. 5
24
