View the Connection Status
When the 1 Beyond Camera manager software connects to a camera, the camera shows as connected
in the Main session and Sub session columns. These columns indicate the camera's main and
substreams connection status for IP(RTSP)video.
NOTE:When the chosen camera is set to match your IPaddress, its status will read connected for
both columns.
The following connection status messages can be shown for a camera:
l
Connected:The 1 BeyondCamera Manager software has received RTSPvideo streams from the
camera and has connected to the camera.
l
Connection Failed:The 1 BeyondCamera Manager software discovered the camera on the
network, but video streams cannot be received. The camera is likely connected to a different
subnet from the host computer.
l
Disconnected:The camera is not currently accessible on the network.
NOTE:When a camera is first connected to the network, it can take up to 30 seconds after
powering the camera on for it to be discovered by the 1 BeyondCamera Manager software. This is
because the camera performs a diagnostic routine prior to activating the video encoder.
Configure Camera Settings
Once a camera has been added to the 1 BeyondCamera Manager software as described in Device
Management, select Settings to configure general settings for the camera.
Camera Manager - Settings Button
Selecting Settings opens the Camera Configuration dialog box, which provides access to many of the
camera's system settings.
Camera Configuration Dialog Box
