Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System
Leading Specifications of the 2-Series Integrated Control System
SPECIFICATION DETAILS
Power Requirements
100-240 VAC, 2.4 A, 50/60 Hz
Internal Universal Power Supply
SIMPL
TM
Windows
®
Version 2.00 or later
1
Crestron Database
Version 15.6.2 or later
1
2-Series Control System Update File
2
Version 1.000.CUZ or later
3
Reset Buttons
HWR (permits physical reset of system) &
SWR (system restart with or without program)
LCD Display
(1) reverse mode (yellow on black) LCD back light;
(2) lines, (40) characters per line.
4
Network Power Fuse Rating
4A, 250V (1
1
/
4
" x
1
/
4
" Slow Blow Fuse Series)
Environmental Temperature Range
41
o
to 113
o
F (5
o
to 45
o
C)
Environmental Humidity
10% to 90% RH (non-condensing)
Dimensions & Weight
Height: 3.47 in (8.81 cm)
Width: 19.00 in (48.26 cm) - with ears
17.03 in (43.24 cm) - without ears
Depth: 9.69 in (24.61 cm)
Weight: 7.10 lb (3.22 kg) for AV2 with line cord
8.00 lb (3.62 kg) for PRO2 with line cord
1
The latest software versions can be obtained from the What's New page (SIMPL Windows and
Crestron Database sections) or Downloads page (SIMPLWIN and CRESDB Libraries) of the
Crestron website (www.crestron.com)
. New users are required to register in order to obtain access to
the FTP site.
2 Crestron 2-Series control systems include the AV2, AV2 with Card Cage, CP2, CP2E, PAC2,
PAC2M, PRO2, and RACK2.
3 Filenames for 2-Series control system update files have a CUZ extension and can be obtained from
the What's New page (Control Systems Update Files section) or Downloads page (OPSYS Library)
of the Crestron website.
4 The LCD display is not available on the AV2.
Leading Specifications of the 2-Series Connectors
CONNECTOR DETAILS
NET (1) 4-pin male connector for expansion to Cresnet or SmarTouch
peripherals.
50 Watt maximum load depending on expansion slot load
RELAYS (8) normally open,isolated relays; each relay is rated 1 A, 30 VAC/DC MOV
arc suppression devices across contacts for use with "real world" loads
INPUT/OUTPUT (8) programmable digital/analog inputs & digital outputs; digital outputs
offer 250 mA sync from maximum 24 VDC; catch diodes for use with "real
world" loads; digital inputs rated for 0-24 VDC, 20 K ohms input impedance,
logic threshold 1.25 VDC; analog inputs rated 1-10 VDC, protected to
24 VDC maximum, 20 K ohms input impedance; programmable 2 K ohms
pullup resistor (per pin, software reference to GND or closure to GND)
IR/SERIAL (8) serial outputs or IR, RS-232, or serial interface; signal (S) and ground
(G) pins, infrared output up to 1.2 MHz, serial protocols include RS-232
COM (6) bidirectional serial ports for RS-232, RS-422, or RS-485 communication
with hardware and software handshaking; speeds up to 115,000 baud
COMPUTER (2) 9-pin DB9 female connector for programming with a PC; modem
compatible, null modem cable; not included
Operations Guide - DOC. 5957 Integrated Dual Bus Control System: PRO2 & AV2 • 11
