Crestron 2 Series - Setup; Rack Mounting

2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2
Leading Specifications of the 2-Series Slots
SLOT DETAILS
Memory Compact flash slot (up to 4GB) accepts standard Type II Compact Flash
or IBM Microdrive
®
Y-BUS (3) open "card cage" slots provides 40 Mb/s parallel communications and
supports current and enhanced Crestron control cards
5
Z-BUS Single slot provides 300 Mb/s parallel commuincations and supports either
the single port 10/100 Ethernet, dual port WAN-LAN-10/100 Ethernet, or
dual port WAN-LAN-10/100 Ethernet-USB
5
CAGE2, 3-card cage, installation required for AV2.
As of the date of manufacture, the unit has been tested and found to comply with
specifications for CE marking.
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
Setup
Rack Mounting
WARNING: To prevent bodily injury when mounting or servicing this unit in a
rack, take special precautions to ensure that the system remains stable. The
following guidelines are provided to ensure your safety:
 The unit should be mounted at the bottom of the rack if it is the only unit in the
rack.
 When mounting this unit in a partially filled rack, load the rack from the bottom
to the top with the heaviest component at the bottom of the rack.
 If the rack is provided with stabilizing devices, install the stabilizers before
mounting or servicing the unit in the rack.
NOTE: If rack mounting is not required, rubber feet are provided for table-top
mounting or stacking. Apply the feet near the corner edges on the underside of the
unit.
NOTE: Reliable earthing of rack mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct
connections to the branch circuit. (e.g., use of power strips).
Two “ears” are provided with the 2-Series integrated dual bus control system so that
the unit can be rack mounted. These ears must be installed prior to mounting.
12 • Integrated Dual Bus Control System: PRO2 & AV2 Operations Guide - DOC. 5957
