Crestron CP3N User Manual

3-Series Control Systems Crestron CP3 & CP3N
6 • 3-Series Control Systems: CP3 & CP3N Operations Guide – DOC. 7316C
CP3 Specifications (Continued)
SPECIFICATION DETAILS
Environmental
Temperature 41º to 113º F (5º to 45º C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 50 Btu/h
Enclosure
Chassis Metal, black finish
Faceplate Extruded metal, black finish, polycarbonate
label overlay
Mounting Freestanding or 1U 19-inch rack-mountable
(adhesive feet and rack ears included)
Dimensions
Height 1.70 in (44 mm) without feet
Width 17.28 in (439 mm)
19.00 in (483 mm) with rack ears
Depth 6.56 in (167 mm)
Weight 3.1 lbs (1.42 kg)
Included Accessory
Power Pack 24 volt dc, Universal
Available Accessories
3-Series BACnet/IP
Support
3-Series Native BACnet/IP Interface License
C2N-HBLOCK Cresnet Network Distribution Block
CEN-SW-POE-16 16-Port Managed PoE Switch
CEN-SW-POE-24 24-Port Managed PoE Switch
CEN-SW-POE-5 5-Port PoE Switch
CNSP-XX Custom Serial Interface Cable
Crestron Mobile Control App for iPhone and iPod touch
Crestron Mobile Pro G Control App for iPhone, iPad, and Android
Devices
CSP-LIR-USB IR Learner
Fusion RV Remote Asset Management Software
IRP2 IR Emitter Probe
myCrestron Dynamic DNS Service for Crestron systems
PWE-4803RU PoE Injector
RoomView Express Remote Help Desk and Resource
Management Software
1. License required. The CP3 and CP3N support a maximum of 1000 BACnet objects when dedicated
for BACnet use only. Actual capabilities are contingent upon the overall program size and complexity
2. Web-based installer setup requires the Microsoft Internet Explorer Web browser running on a
Windows PC.
3. Refer to “Identity Code” on page 11

Crestron CP3N Specifications

General

Internal memory	0.5 GB
Storage media type	Flash
Internal memory type	SDRAM
Internal storage capacity	4 GB
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Heat dissipation	50 BTU/h
Housing material	Metal
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
