3-Series Control Systems Crestron CP3 & CP3N
4 • 3-Series Control Systems: CP3 & CP3N Operations Guide – DOC. 7316C
Fusion RV and SNMP
As part of a complete managed network in a corporate enterprise, college campus,
convention center or any other facility, the CP3 works integrally with Crestron
Fusion RV Remote Asset Management Software to enable remote scheduling,
monitoring, and control of rooms and technology from a central help desk. Built-in
SNMP support enables integration with third-party network management software,
allowing control and monitoring in a format that's familiar to IT personnel.
Cresnet
Cresnet provides a dependable network wiring solution for Crestron keypads,
lighting controls, thermostats, and other devices that do not require the higher speed
of Ethernet. The Cresnet bus offers easy wiring and configuration, carrying
bidirectional communication and 24 Vdc power to each device over a simple
4-conductor cable. To assist with troubleshooting, the CP3 includes Crestron’s patent
pending Network Analyzer which continuously monitors the integrity of the Cresnet
network for wiring faults, marginal performance, and other errors.
Onboard Control Ports
In addition to Ethernet, the CP3 includes three bidirectional COM ports and eight IR
ports to interface directly with all of the centralized AV sources, video displays, and
other devices. Eight programmable relay ports are included for controlling window
shades, projection screens, lifts, power controllers, and other contact closure actuated
equipment. Eight “Versiport” I/O ports enable the integration of occupancy sensors,
power sensors, door switches, or anything else that provides a dry contact closure,
low-voltage logic, or 0-10 volt dc signal.
BACnet/IP
Native support for the BACnet/IP communication protocol provides a direct
interface to third-party building management systems over Ethernet, simplifying
integration with HVAC, security, fire and life safety, voice and data, lighting,
shades, and other systems. Using BACnet/IP, each system runs independently with
the ability to communicate together on one platform for a truly smart building.*
* License required. The CP3 and CP3N support a maximum of 1000 BACnet objects when dedicated
for BACnet use only. Actual capabilities are contingent upon the overall program size and
complexity.
Specifications
Specifications for the CP3 are listed in the following table.
CP3 Specifications
SPECIFICATION DETAILS
Control Engine Core 3 OS; real time, preemptive
multi-threaded/multitasking kernel;
Transaction-Safe Extended FAT file system;
supports up to 10 simultaneously running
programs
(Continued on following page)

Crestron CP3N Specifications

General

Internal memory	0.5 GB
Storage media type	Flash
Internal memory type	SDRAM
Internal storage capacity	4 GB
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Heat dissipation	50 BTU/h
Housing material	Metal
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
