3-Series Control Systems Crestron CP3 & CP3N
20 • 3-Series Control Systems: CP3 & CP3N Operations Guide – DOC. 7316C
Programs and Firmware
Program or firmware files may be distributed from programmers to installers or from
Crestron to dealers. Firmware upgrades are available from the Crestron Web site as
new features are developed after product releases. One has the option to upload
programs via the programming software or to upload and upgrade via the Crestron
Toolbox. For details on uploading and upgrading, refer to the Crestron Studio help
file, SIMPL Windows help file, or the Crestron Toolbox help file.
Crestron Studio /
SIMPL Windows
If a Crestron Studio (or SIMPL Windows) program is provided, it can be uploaded to
the control system using Crestron Studio (or SIMPL Windows) or Crestron Toolbox.
Firmware
Check the Crestron Web site to find the latest firmware. (New users must register to
obtain access to certain areas of the site, including the FTP site.)
Upgrade CP3 firmware via Crestron Toolbox.
1. Establish communication with the CP3 and display the “System Info”
window.
2. Select Functions | Firmware… to upgrade the CP3 firmware.

Crestron CP3N Specifications

General

Internal memory	0.5 GB
Storage media type	Flash
Internal memory type	SDRAM
Internal storage capacity	4 GB
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	24 W
Operating temperature (T-T)	5 - 45 °C
Operating relative humidity (H-H)	10 - 90 %
Product color	Black
Heat dissipation	50 BTU/h
Housing material	Metal
Ethernet LAN (RJ-45) ports	2

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
