Crestron DM-NVX-D30 Design Guide

6 • DM NVX System Design Guide – DOC. 7977F
DM NVX Endpoints (Continued)
FEATURE DM-NVX-350 DM-NVX-350C DM-NVX-351 DM-NVX-351C DM-NVX-352 DM-NVX-352C DM-NVX-E30 DM-NVX-E30C DM-NVX-D30 DM-NVX-D30C
Audio
Inputs 2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
Dante and
AES67
2 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
Dante and
AES67
1 x HDMI 1 x HDMI 1 x DM NVX 1 x DM NVX
Outputs 1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
Dante and
AES67
1 x HDMI,
1 x DM NVX
2
,
5-pin Phoenix
Dante and
AES67
5-pin Phoenix 5-pin Phoenix 1 x HDMI,
5-pin Phoenix
1 x HDMI,
5-pin Phoenix
Digital Input/
Output Audio
Formats
Dolby Digital®,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby® TrueHD,
Dolby Atmos®,
DTS®, DTS ES,
DTS 96/24,
DTS HD® High
Res, DTS HD
Master Audio™,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
Dolby Digital,
Dolby Digital
EX, Dolby
Digital Plus,
Dolby TrueHD,
Dolby Atmos,
DTS, DTS ES,
DTS 96/24,
DTS HD High
Res, DTS HD
Master Audio,
LPCM up to 8
channels
DSP Audio
Downmix
— — Yes Yes — — — — — —
Analog Output
Audio Formats
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Analog Input
Audio Formats
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
— — — —
Secondary Audio
Stream Formats
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
Stereo
2-channel
— — — —
Dante and AES67
Audio Formats
5
— — — —
Stereo
2-channel
48 kHz
Stereo
2-channel
48 kHz
— — — —
Breakaway Audio
6
Yes Yes Yes Yes Yes Yes — — — —
Available DM NVX Streams
Primary AV
Stream
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Secondary Audio
Stream
Yes Yes Yes Yes Yes Yes — — — —
Dante Audio
Stream Transmit/
Receive
— — — — Yes Yes — — — —
AES67 Secondary
Audio Stream
Transmit/Receive
— — — — Yes Yes — — — —
(Continued on following page)

Crestron DM-NVX-D30 Specifications

General

Brand	Crestron
Model	DM-NVX-D30
Category	Media Converter
Language	English
