Crestron DM-NVX-D30 Design Guide

Design Guide – DOC. 7977F DM NVX System • 5
Endpoint Comparison
The following table provides a comparison of the various DM NVX endpoints.
DM NVX Endpoints
FEATURE DM-NVX-350 DM-NVX-350C DM-NVX-351 DM-NVX-351C DM-NVX-352 DM-NVX-352C DM-NVX-E30 DM-NVX-E30C DM-NVX-D30 DM-NVX-D30C
General
Description
Premium
network AV
encoder/
decoder
Premium
network AV
encoder/
decoder
Premium
network AV
encoder/
decoder with
DSP
downmixing
Premium
network AV
encoder/
decoder with
DSP
downmixing
Premium
network AV
encoder/
decoder with
Dante® and
AES67
networking
Premium
network AV
encoder/
decoder with
Dante and
AES67
networking
Basic network
AV encoder
Basic network
AV encoder
Basic network
AV decoder
Basic network
AV decoder
Form Factor
Surface
mountable
Card
Surface
mountable
Card
Surface
mountable
Card
Surface
mountable
Card
Surface
mountable
Card
Video
Inputs
2 x HDMI® (DVI
compatible)
1
,
1 x DM NVX™
2
2 x HDMI (DVI
compatible)
1
,
1 x DM NVX
2
2 x HDMI (DVI
compatible)
1
,
1 x DM NVX
2
2 x HDMI (DVI
compatible)
1
,
1 x DM NVX
2
2 x HDMI (DVI
compatible)
1
,
1 x DM NVX
2
2 x HDMI (DVI
compatible)
1
,
1 x DM NVX
2
1 x HDMI (DVI
compatible)
1
1 x HDMI (DVI
compatible)
1
1 x DM NVX 1 x DM NVX
Output
HDMI (DVI
compatible)
3
HDMI (DVI
compatible)
3
HDMI (DVI
compatible)
3
HDMI (DVI
compatible)
3
HDMI (DVI
compatible)
3
HDMI (DVI
compatible)
3
— —
HDMI (DVI
compatible)
3
HDMI (DVI
compatible)
3
Maximum
Input/Output
Resolution
4K60 4:4:4 4K60 4:4:4 4K60 4:4:4 4K60 4:4:4 4K60 4:4:4 4K60 4:4:4 4K60 4:4:4 4K60 4:4:4 4K60 4:4:4 4K60 4:4:4
Custom
Resolutions
Supported at
pixel clock
rates up to
600 MHz
Supported at
pixel clock
rates up to
600 MHz
Supported at
pixel clock
rates up to
600 MHz
Supported at
pixel clock
rates up to
600 MHz
Supported at
pixel clock
rates up to
600 MHz
Supported at
pixel clock
rates up to
600 MHz
Supported at
pixel clock
rates up to
600 MHz
Supported at
pixel clock
rates up to
600 MHz
Supported at
pixel clock
rates up to
600 MHz
Supported at
pixel clock
rates up to
600 MHz
Output Scaler
2
Yes Yes Yes Yes Yes Yes — — — —
Video Wall Mode 8 x 8 8 x 8 8 x 8 8 x 8 8 x 8 8 x 8 8 x 8 8 x 8 — —
Widescreen
Format Selection
Yes Yes Yes Yes Yes Yes — — — —
Underscan Yes Yes Yes Yes Yes Yes — — — —
Maximum HDCP HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2 HDCP 2.2
HDCP
Input/Output
Configurable
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Input EDID Control Yes Yes Yes Yes Yes Yes Yes Yes — —
Auto-Routing Yes Yes Yes Yes Yes Yes — — — —
Input Selection Yes Yes Yes Yes Yes Yes — — — —
Deep Color Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
HDR10 Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Video Timeout
Control
2
Yes Yes Yes Yes Yes Yes — — — —
Crestron®
QuickSwitch HD™
4
Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
On-Screen Display
Basic Text Overlay
Yes Yes Yes Yes Yes Yes — — Yes Yes
(Continued on following page)

Crestron DM-NVX-D30 Specifications

General

Brand	Crestron
Model	DM-NVX-D30
Category	Media Converter
Language	English
