Crestron DM-TX-201-C Supplemental Guide

12 • DM-TX-201-C Supplemental Guide — Doc. 6958E
DM OUT Pin Assignments and Wiring
Pin Number Wire Color
1 Orange/White
2 Orange
3 Green/White
4 Blue
5 Blue/White
6 Green
7 Brown/White
8 Brown
LAN Pin Assignments
Pin Number Signal
1 TX+
2 TX–
3 RX+
4 N/C
5 N/C
6 RX–
7 N/C
8 N/C

Crestron DM-TX-201-C Specifications

General

Type	Network transmitter
Duplex system	Full, Half
Auto-negotiation	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3at
RJ-45 ports quantity (transmitter)	2
Product color	Black
Output current	0.75 A
Output voltage	24 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	32 mm
Width	187 mm
Height	165 mm
Weight	721 g
