Crestron DM-TX-201-C Supplemental Guide

Supplemental Guide — Doc. 6958E DM-TX-201-C • 1
Introduction
The Crestron® DM-TX-201-C provides an interface for computers and high-definition AV
sources as part of a complete Crestron DigitalMedia™ system. DM-TX-201-C functions as
a DM 8G+® transmitter and switcher, providing HDMI ®, RGB, and analog audio inputs as
well as Ethernet and USB HID ports. In addition to compatibility with other DM 8G+
devices, the DM-TX-201-C is also compatible with HDBaseT® compliant devices.
The DM-TX-201-C provides simple switching between the HDMI and RGB inputs. The inputs
can be configured to switch automatically or can be controlled through a Crestron control
system. Analog audio breakaway capability enables the analog audio input of the
DM-TX-201-C to be used with either video input. The DM-TX-201-C also functions as a
keyboard/mouse extender, allowing the connected USB HID compliant host to be
controlled by a mouse and/or keyboard that is located at a remote location.
Additional features of the DM-TX-201-C include the following:
l Local HDMI output, which enables pass-through of the selected video and audio
signals to feed a local display, monitor, or sound system
l 10BASE-T/100BASE-TX LAN port, which can be used to provide a convenient LAN
connection for a local network device
l CEC embedded device control, which provides a gateway for controlling the
connected source device through the HDMI connection
l Compatibility with TT-100 Series devices (Crestron Connect It™ cable caddies)
l Detection and reporting of detailed video and audio information via DMTool
This guide provides information about the following:
l Physical description of the side views of the DM-TX-201-C
l Communications using Crestron Toolbox™ software
l Troubleshooting
l Pin assignments
For installation information, refer to the DM-TX-201-C Quick Start Guide (Doc. 7719) at
www.crestron.com/manuals.

Crestron DM-TX-201-C Specifications

General

Type	Network transmitter
Duplex system	Full, Half
Auto-negotiation	Yes
Ethernet LAN data rates	10, 100 Mbit/s
Maximum transfer distance	- m
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3at
RJ-45 ports quantity (transmitter)	2
Product color	Black
Output current	0.75 A
Output voltage	24 V
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	32 mm
Width	187 mm
Height	165 mm
Weight	721 g
