4 • DM-TX-201-C Supplemental Guide — Doc. 6958E
Ê
SETUP: Red LED and miniature recessed push button for Ethernet setup
Ë
AUDIO IN: 3.5 mm TRS mini phone jack;
Unbalanced stereo line level audio input;
Input level: 2 Vrms maximum;
Input impedance: 10 k ohms
Ì
RGB IN: HD15 female;
Analog VGA/RGB/video input;
Signal types: VGA, RGB, component, S-Video, or composite ;
Formats: RGBHV, RGBS, RGSB, YPbPr, Y/C, NTSC, PAL;
Input levels: 0.5 to 1.5 Vp-p with built-in DC restoration;
Input impedance: 75 ohms;
Sync input type: Autodetect RGBHV, RGBS, RGSB, YPbPr;
Sync input level: 3 to 5 Vp-p;
Sync input impedance: 1 k ohm
NOTE:The RGB input can accept component, composite, and S-Video signals
through an appropriate adapter (not included) or via direct interface to the
Crestron MPS Series products. However, input sync detection is not provided for
composite or S-Video signal types through this connection.
Í
RGB IN LED: Green LED, indicates RGB input is selected
Î
HDMI IN: 19-pin Type A HDMI female;
HDMI digital video/audio input (DVI and Dual-Mode DisplayPort compatible)
NOTE: The HDMI IN connection requires an appropriate adapter or interface
cable to accommodate a DVI or Dual-Mode DisplayPort signal. CBL-HD-DVI
interface cables are available separately.
Ï
HDMI IN LED: Green LED, indicates HDMI input is selected
Ð
USB HID: USB Type B female;
USB 2.0 device port for connection to the USB host interface of a computer or other
USB HID compliant host device, or for connection of a Crestron TT-100 Series device
(Crestron Connect It cable caddy)
NOTE: The USB HID port does not supply USB power. When connected to a
TT-100 Series device (sold separately), the TT-100 Series device must be powered
separately through a connection to a Cresnet® network or power supply.
