Crestron DM-TX-4K-202-C Supplemental Guide

Supplemental Guide – DOC. 7932A DM-TX-4K-202-C/DM-TX-4K-302-C: 4K DigitalMedia 8G+ Transmitters • 1
DM-TX-4K-202-C/DM-TX-4K-302-C:
4K DigitalMedia 8G+
®
Transmitters
Introduction
The Crestron
®
DM-TX-4K-202-C and DM-TX-4K-302-C are DigitalMedia 8G+
®
transmitters
and switchers that provide support for the transport of 4K and Ultra HD video signals.
The DM-TX-4K-202-C and DM-TX-4K-302-C provide two HDMI
®
inputs. In addition to the
HDMI inputs, the DM-TX-4K-302-C provides one VGA input and one analog audio input.
The DM-TX-4K-202-C and DM-TX-4K-302-C also function as control modules, providing
RS-232 and IR control ports. An Ethernet port and a USB HID port are also provided.
This guide provides information about the following:
• Physical description of the side views of the DM-TX-4K-202-C and
DM-TX-4K-302-C
• Configuration of some of the capabilities of the DM-TX-4K-202-C and
DM-TX-4K-302-C, for example, automatic audio/video signal format management
via EDID
• HDCP 2.2. compliance
• Troubleshooting
• Pin assignments
For additional information, refer to the DM-TX-4K-202-C/DM-TX-4K-302-C DO Guide
(Doc. 7743) at www.crestron.com/manuals
.

Crestron DM-TX-4K-202-C Specifications

General

Brand	Crestron
Model	DM-TX-4K-202-C
Category	Transmitter
Language	English
