Supplemental Guide – DOC. 7932A DM-TX-4K-202-C/DM-TX-4K-302-C: 4K DigitalMedia 8G+ Transmitters • 3
HDMI IN 1–2 LEDs: Green LEDs, each indicates HDMI signal presence at the
corresponding HDMI input
HDMI IN 1–2: 19-pin Type A HDMI female;
HDMI digital video/audio inputs;
(DVI and Dual-Mode DisplayPort compatible)
NOTE: The HDMI IN ports require an appropriate adapter or interface cable to
accommodate a DVI or Dual-Mode DisplayPort signal. The CBL-HD-DVI interface cable
is available separately.
DM OUT: 8-pin RJ45 female, shielded;
DM 8G+
®
output, HDBaseT
®
standard compliant;
PoDM+ PD (Powered Device) port (IEEE 802.3at Type 2 Class 4 [25.5 W] compliant
and HDBaseT PoE+ compatible) on DM-TX-4K-302-C;
PoDM PD port (IEEE 802.3at Type 1 Class 3 [12.95 W] compliant and HDBaseT PoE
compatible) on DM-TX-4K-202-C;
Connects to the DM 8G+ input of a DM
®
switcher, receiver, or other DM device, or to
an HDBaseT device via CAT5e, Crestron DM-CBL-8G, or Crestron DM-CBL-ULTRA
cable;
Green LED indicates DM link status;
Solid amber LED indicates HDCP video;
Blinking amber LED indicates non-HDCP video
NOTE: Receiving PoDM+ or PoDM requires connection to a switcher or other
equipment that has a corresponding PoDM+ or PoDM PSE (Power Sourcing
Equipment) port. Receiving HDBaseT PoE+ or HDBaseT PoE requires connection to a
switcher or other equipment that has a corresponding HDBaseT PoE+ or HDBaseT
PoE PSE port. Any wiring that is connected to a PoDM+, PoDM, HDBaseT PoE+, or
HDBaseT PoE PSE port is for intrabuilding use only and should not be connected to a
line that runs outside of the building in which the PSE is located.
NOTE: If the DM-TX-4K-302-C does not connect to the included power pack, the
DM-TX-4K-302-C requires PoDM+ or HDBaseT PoE+ to power a USB device
connected to the USB HID port. Standard PoDM or HDBaseT PoE can be used to
power the DM-TX-4K-302-C if no USB device connects to the USB HID port. Unlike for
the DM-TX-4K-302-C, standard PoDM or HDBaseT PoE can be used to power a USB
device connected to the USB HID port of the DM-TX-4K-202-C.
Power LED: Green LED, indicates operating power supplied via PoDM+, PoDM,
HDBaseT PoE+, or HDBaseT PoE for the DM-TX-4K-302-C; PoDM or HDBaseT PoE
for the DM-TX-4K-202-C; or local power pack
24 VDC 0.75A: 2.1 x 5.5 mm dc power connector;
24 Vdc power input;
Power pack included
Ground ( ):: 6-32 screw, chassis ground lug
For pin assignment information, refer to the Appendix on page 11.
