Crestron Isys TPS-6L User Manual

Isys
®
5.7” Wall Mount Touchpanel Crestron TPS-6L
TPS-6L Specifications (Continued)
SPECIFICATION DETAILS
Enclosure
Construction
Injection molded plastic, flush mountable
using (4) clips provided (additional mounting
kits available)
Faceplate
Injection molded plastic, button and no-button
faceplates included, optional solid or backlit
engraving sold separately
Dimensions
Height 5.60 in (14.23 cm)
Width 7.40 in (18.80 cm)
Depth
2.28 in (5.78 cm)
3.58 in (9.08 cm) with SPK-6L speaker kit
(sold separately)
Weight 1.52 lbs (0.69 kg)
Available Models
TPS-6LA-T
Isys 5.7” Wall Mount Touchpanel, Almond,
Textured
TPS-6LB-T
Isys 5.7” Wall Mount Touchpanel, Black,
Textured
TPS-6LW-T
Isys 5.7” Wall Mount Touchpanel, White,
Textured
Included Accessories
TPS-6L-FP(A,B,W)-T
Button Faceplate w/o Engraving
(specify color)
TPS-6L-FP(A,B,W)-T-NB
No-Button Faceplate w/o Engraving (specify
color)
Available Accessories
SPK-6L Speaker Kit
TPS-6L-FP(A,B,W)-T
Button Faceplate w/Custom Engraving
(specify color)
TPS-6L-FP-BKLT-(A,B,W)-T
Backlit Button Faceplate w/Custom Engraving
(specify color)
TPS-6L-FP(A,B,W)-T-NB
No-Button Faceplate w/Custom Engraving
(specify color)
BB-6L Pre-Construction Wall Mount Back Box
PMK-6L Pre-Construction Wall Mount Kit
TMK-6L Trim Ring
MMK-6L Mud Ring
WMKT-6L
Lectern or Post-Construction Wall Mount Kit
with Trim Ring
WMKM-6L
Post-Construction Wall Mount Kit
with Mud Ring
WMKB-6L Replacement Wall Mount Clips
RMK-6L Rack Mount Kit
CresCAT
®
D Crestron Home CAT5 Balanced AV Cable
1. The panel will not load dynamic graphics if they are located on a password protected HTTP server.
2. The latest software versions can be obtained from the Crestron website. Refer to the NOTE following
these footnotes.
6 • Isys
®
5.7” Wall Mount Touchpanel: TPS-6L Operations & Installation Guide - DOC. 6630A
