Crestron Isys TPS-6L User Manual

Crestron TPS-6L Isys
®
5.7” Wall Mount Touchpanel
TPS-6L Specifications (Continued)
SPECIFICATION DETAILS
Touchscreen Display (Continued)
Viewing Angle ±80º horizontal, +80º/-70º vertical
Touchscreen Resistive membrane
Processor
CPU 32-bit Freescale ColdFire
®
Microprocessor
Memory
SDRAM 32 MB
Flash 32 MB
Maximum Project Size 28 MB
Graphic Engine
Isys engine; 16-bit non-palette graphics;
65536 colors; Synapse image rendering
algorithm; multi-mode objects; dynamic
graphics
1
; PNG translucency, full motion
(60 fps) animation; color key video windowing
Ethernet
10BaseT/100BaseTX, auto switching,
auto-negotiating, autodiscovery, full/half
duplex, TCP/IP, UDP/IP, CIP, DHCP, IEEE
802.3U compliant
Video
Signal Types Composite
Formats NTSC 480i or PAL 576i
Color Depth 18-bit, 262,144 colors
Windowing
Single window, deinterlaced and scalable up
to full screen
Audio
Hardware Features
Built-in microphone, internal speaker for
WAV/keyclick, optional amplified speaker for
program/intercom, internal volume & tone
control
Audio Feedback (WAV) 8-bit, PCM, mono, 8 kHz sampling rate
Amplification
0.75 Watt for internal WAV/keyclick speaker,
6 Watts for optional program/intercom
speaker (requires SPK-6L speaker kit, sold
separately)
Power Requirements
Cresnet Power Usage 15 Watts (0.625 Amp @ 24 Volts DC)
Default Net ID 03
Minimum 2-Series Control
System Update File
2, 3
Version 3.137 or later
Environmental
Temperature 32º to 104ºF (0º to 40ºC)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 51 BTU/Hr
(Continued on following page)
Operations & Installation Guide – DOC. 6630A Isys
®
5.7” Wall Mount Touchpanel: TPS-6L • 5

Crestron Isys TPS-6L Specifications

General

Brand	Crestron
Model	Isys TPS-6L
Category	Touch Panel
Language	English
