Crestron TPS-6L Isys
®
5.7” Wall Mount Touchpanel
• With the LINE-IN button set to ON (default), you can adjust the volume as
well as the bass and treble levels. Pressing the LINE IN button turns it to
OFF.
• Press Return to return to the SETUP MENU.
Video Menu
To set the video parameters, select the Video button located on the SETUP MENU
and display the VIDEO SETUP menu, shown below.
VIDEO SETUP Menu
• Adjust the controls as desired for best viewing under local conditions.
NOTE: A video signal must be present in order to view the affects of
adjusting the controls.
• The blue Video area is provided to preview the effect of the translucency
settings. (“Preview Translucency” is a label, not a button.)
• Touch the Video area to change it to a full screen display, as shown in the
following illustration.
• Press Restore Default Color Settings as necessary to cancel all setting
changes.
• Press Hide Controls to remove the controls from the display. The button
legend changes to Show Controls to let you display them for further
adjustment.
Operations & Installation Guide – DOC. 6630A Isys
®
5.7” Wall Mount Touchpanel: TPS-6L • 21
