Isys
®
5.7” Wall Mount Touchpanel Crestron TPS-6L
• Additional TPS-6L devices are assigned different Net ID (for Cresnet
devices) or IP ID (for Ethernet devices) numbers as they are added.
• If necessary, double click a device to open the “Device Settings” window
and change the Net ID or IP ID, as shown in the following figures.
“TPS-6L Device Settings” Net ID Window
“TPS-6L Device Settings” IP ID Window
• The ID code specified in the SIMPL Windows program must match the Net
ID or IP ID of each unit. Refer to “Identity Code” on page 12.
Program Manager
Program Manager is the view where programmers “program” a Crestron control
system by assigning signals to symbols.
The symbol can be viewed by double clicking on the icon or dragging it into Detail
View. Each signal in the symbol is described in the SIMPL Windows help file (F1).
38 • Isys
®
5.7” Wall Mount Touchpanel: TPS-6L Operations & Installation Guide - DOC. 6630A
