Product Manual Doc. 8550E TSW-70Series5
XiOCloudService
The TSW-570 is compatible with the XiO Cloud® service, which is an IoT (Internet of Things)
based platform for remotely provisioning, monitoring, and managing Crestron devices across an
enterprise or an entire client base. Built on the Microsoft® Azure® software platform and utilizing
Microsoft's industry-leading Azure IoT Hub technology, XiO Cloud enables installers and IT
managers to deploy and manage thousands of devices in the time it previously took to manage
just one. Unlike other virtual machine-based cloud solutions, Azure services provide unlimited
scalability to suit the ever-growing needs of an enterprise. For more information, visit
www.crestron.com/xiocloud.
Wall Mount Options
The TSW-570 is easily installed into drywall and other surfaces using the included TSW-UMB-70
universal mounting bracket, which affords the following mounting options:
4
l
Can be used by itself as a postconstruction solution for retrofitting the TSW-570 into
existing drywall.
l
Can be used with the included TSW-UMB-70-PMK preconstruction mounting kit for
applications that don’t require a back box.
l
Can be used with the TSW-UMB-70-BBI back box for masonry and concrete applications.
1
A security bracket option is also included to deter unauthorized removal of the touch screen.
OptionalMounting Accessories
The TSW-570/770-RMK-1 rack mount kit allows the touch screen to be mounted into a 19 in.
rack. When installed, the touch screen occupies three rack spaces.
1
The TSW-570 is also compatible with Wall-Smart® flush wall mount products via a partnership
with Crestron. For more information on supported Wall-Smart hardware, click here.
Notes:
1. Item(s) sold separately. Refer to each product’s spec sheet for complete information.
2. Web browsing, weather information, and certain other functions require an Internet connection.
3. Room scheduling mode requires the TSW-570 to be designated exclusively for room scheduling use, which
precludes use of certain features and functions described in this spec sheet. For design assistance, contact the
Crestron True Blue support team at www.crestron.com/support.
4. The TSW-UMB-70 is also compatible with older TSW-UMB-PMK series preconstruction mounting kits and
TSW-BBI series back boxes, allowing the TSW-570 to be installed in place of a previous generation touch screen.
