Croplands Pinto 2000 - Page 47

3.4
Pinto BT-POM 1212 - Revision 5
Sprayer Operation
Optional RHS 20 l/min foam marker.Optional Salvarani foam marker tank.
The Fresh Water/Hand rinse tap - 3000 litre.
The Fresh Water/Hand rinse tap - 2000 litre.
(1) Unscrew the tank lid for fi lling (3000 litre).
(1) Unscrew the tank lid for fi lling (2000 litre).
Always add foam concentrate after fi lling tank
with water to minimise foaming when fi lling.
NOTE
3 Foam Marker Tanks
If your Pinto is fi tted with the optional
Salvarani or RHS foam marker, fi ll with
clean fresh water (preferably rainwater).
Use the tank lid for top-fi lling and adding
foam concentrate.
To fi ll foam marker tanks:
1 Unscrew the tank lid.
2 Fill the tank with the required amount
of water
3 Replace the lid after fi lling.
4 Fresh Water Tank
The Pinto incorporates a 30 litre fresh
water tank for personal safety when
operating the unit in the fi eld.
Always fi ll the fresh water tank before
spraying.
To fi ll the fresh water tank:
1 Unscrew the tank lid.
2 Fill the tank using only rainwater.
3 Replace the lid after fi lling.
Filling
