4.9
Pinto BT-POM 1212 - Revision 5
Section 4
XR TeeJet Nozzle Chart
Nozzle
(fi lter)
Bar l/min 4km/h 5km/h 6km/h 7km/h 8km/h 10km/h 12km/h 16km/h 18km/h 20km/h 25km/h 30km/h 35km/h
1.0 0.23 69.0 55.2 46.0 39.4 34.5 27.6 23.0 17.3 15.3 13.8 11.0 9.2 7.9
1.5 0.28 84.0 67.2 56.0 48.0 42.0 33.6 28.0 21.0 18.7 16.8 13.4 11.2 9.6
2.0 0.32 96.0 76.8 64.0 54.9 48.0 38.4 32.0 24.0 21.3 19.2 15.4 12.8 11.0
3.0 0.39 117 93.6 78.0 66.9 58.5 46.8 39.0 29.3 26.0 23.4 18.7 15.6 13.4
4.0 0.45 135 108 90.0 77.1 67.5 54.0 45.0 33.8 30.0 27.0 21.6 18.0 15.4
1.0 0.34 102 81.6 68.0 48.3 51.0 40.8 34.0 25.5 22.7 20.4 16.3 13.6 11.7
1.5 0.42 126 101 84.0 72.0 63.0 50.4 42.0 31.5 28.0 25.2 20.2 16.8 14.4
2.0 0.48 144 115 96.0 82.3 72.0 57.6 48.0 36.0 32.0 28.8 23.0 19.2 16.5
3.0 0.59 177 142 118 101 88.5 70.8 59.0 44.3 39.3 35.4 28.3 23.6 20.2
4.0 0.68 204 163 136 117 102 81.6 68.0 51.0 45.3 40.8 32.6 27.2 23.3
1.0 0.46 138 110 92.0 78.9 69.0 55.2 46.0 34.5 30.7 27.6 22.1 18.4 15.8
1.5 0.56 168 134 112 96.0 84.0 67.2 56.0 42.0 37.3 33.6 26.9 22.4 19.2
2.0 0.65 195 156 130 111 97.5 78.0 65.0 48.8 43.3 29.0 31.2 26.0 22.3
3.0 0.79 237 190 158 135 119 94.8 79.0 59.3 52.7 47.4 37.9 31.6 27.1
4.0 0.91 273 218 182 156 137 109 91.0 68.3 60.7 54.6 43.7 36.4 31.2
1.0 0.68 204 163 136 117 102 81.6 68.0 51.0 45.3 40.8 32.6 27.2 23.3
1.5 0.83 249 199 166 142 125 100 83.0 62.3 55.3 49.8 39.8 33.2 28.5
2.0 0.96 288 230 192 165 144 115 96.0 72.0 64.0 57.6 46.1 38.4 32.9
3.0 1.18 354 283 236 202 177 142 118 88.5 78.7 70.8 56.6 47.2 40.5
4.0 1.36 408 326 272 233 204 163 136 102 90.7 81.6 65.3 54.4 46.6
1.0 0.91 273 218 182 156 137 109 91.0 68.3 60.7 54.6 43.7 36.4 31.2
1.5 1.12 336 269 224 192 168 134 112 84.0 74.7 67.2 53.8 44.8 38.4
2.0 1.29 387 310 258 221 194 155 129 96.8 86.0 77.4 61.9 51.6 44.2
3.0 1.58 474 379 316 271 237 190 158 119 105 94.8 75.8 63.2 54.2
4.0 1.82 546 437 364 312 273 218 182 137 121 109 87.4 72.8 62.4
1.0 1.14 342 274 228 195 171 137 114 85.5 76.0 68.4 54.7 45.6 39.1
1.5 1.39 417 334 278 238 209 167 139 104 92.7 83.4 66.7 55.6 47.7
2.0 1.61 483 386 322 276 242 193 161 121 107 96.6 77.3 64.4 55.2
3.0 1.97 591 473 394 338 296 236 197 148 131 118 94.6 78.8 67.5
4.0 2.27 681 545 454 389 341 272 227 170 151 136 109 90.8 77.8
XR11001
AI11001
(100 mesh)
XR110015
AI110015
(100 mesh)
XR11002
AI11002
(50 mesh)
XR11003
AI11003
(50 mesh)
XR11004
AI11004
(50 mesh)
XR11005
AI11005
(50 mesh)
Litres/ha @ 500mm nozzle spacing
[
XR = Extended Range
]
