Crowcon Gasmaster Menu system overview
25
Press
CONTINUE
Faults
Warnings
View
Action
Supervisor
Figure 3.5 Overview of Gasmaster Menu system
Faults Menu
List of faults
present
Warnings
Menu
List of warnings
present
View Menu
Relay com stat
Relay chan stat
Output status
Input status
Supply status
Configuration
Action Menu
Display contrast
Control panel
Audio visual
Supervisor
Menu
Password
Inhibit
Pellistor Saver
Zero
Calibrate
Test
Configure
View:
Relay com stat
Alarm L1 common
Alarm L2 common
Fault common
View:
Configuration
System
Language
AV drive
Relay common
Channels 1 to 4*
View:
Configuration:
Relays common
Alarm L1 common
Alarm L2 common
Common Fault
View:
Configuration:
Channels 1 to 4*
Type
Name
Location
Units
†
Range
†
Zero suppression
†
Interpret 2 mA
†
Stab time
Fire reset time
‡
Alarm 1
Alarm 2
Note:
* Menu items are hidden for
unused channels
†
Visible only for 4-20 mA
Sink/SRC
‡
Visible only for Fire conv type
^Not present for Alarm 2
Supervisor:
Test
Relays common
Channels 1 to 4*
Supervisor:
Configuration
System
Language
AV drive
Relay common
Channels 1 to 4*
Supervisor:
Configuration:
Relay common
Alarm L1 common
Alarm L2 common
Common Fault
Supervisor:
Configuration:
Channels #1 to
4*
Type
Name
Location
Units
†
Range
†
Zero suppression
†
Interpret 2 mA
†
Stab time
Fire reset time
‡
Alarm 1
Alarm 2
All Supervisor Menu
options are password
protected, see page 20
for details of this menu
section.
View:
Relay chan stat
Alarm L1
(Channels 1 to 4)*
Alarm L2
(Channels 1 to 4)*
Supervisor:
Configuration:
Channels #1 to 4*
Alarm 1 & Alarm 2
Direction
On threshold
Off threshold^
Relay type
Relay drive
Indication^
(See Supervisor
configuration)
